Aaronia MDF930X – Magnetic Field Tracking Antenna, 9KHz to 30MHz
18 people are viewing this product right now
$1,581.36
Shipping calculated at checkout.
Estimated delivery:5 days
MDF 930X (9kHz – 30MHz, active with 35dB pre-amplifier)
- Magnetic tracking antenna
- Frequency range: 9KHz to 30MHz (Active)
- Perfect for magnetic field direction finding in combination with Spectrum Analyzers
- Compact design and low weight
- Compatible with any Spectrum Analyzer brand
- Incl. Pistol grip with mini tripod function & watertight transport case
Guarantee Safe and Secure Payment Checkout
Description
Aaronia MDF930X – Magnetic Field Tracking Antenna, 9KHz to 30MHz
- Magnetic tracking antenna
- Frequency range: 9KHz to 30MHz (Active)
- Perfect for magnetic field direction finding in combination with Spectrum Analyzers
- Compact design and low weight
The Aaronia MDF930X is a broadband, active magnetic field tracking antenna, suitable for signal tracking and field strength measurements. It offers a frequency range from 9KHz to 30MHz (Active).
Aaronia presents the new, high quality magnetic field tracking antennas of the MDF series, suitable for signal tracking and field strength measurement. Available in 5 different versions (2 passive, 3 active), the MDF covers an extremely broad frequency range from 9kHz to 400MHz. Together with the MDF antennas, any regular Spectrum Analyzer transforms into a Magnetic Field Meter with tracking function in a few simple steps.
Compact, Inexpensive, Directional and Highly Sensitive
The special conversion factor of the MDF, in conjunction with a Power Meter showing dBm values, gives a direct dBA/m display with correct sign (power meter function).
Thanks to the high directionality of the antenna, the MDF is ideally suited for signal direction finding. This predestines the MDF to use as a radio direction finder or to locate illegal or unwanted interference. Designed and manufactured in Germany, each MDF Antenna stands for highest quality standards. To illustrate this point every MDF offers a full 10 years warranty period.
Frequency Response (Power Meter Function)
E-Field Suppression
Accessories/Antennas Template | |
|---|---|
| Type (Antennas) | Other Type (Antennas) Active Loop |
| Maximum Frequency Range | 30 MHz |
| Magnetic Base | Yes |
Product General Attributes | |
| Unique Features | Frequency Range: 9kHz – 30MHz (1MHz – 25MHz with max. +/- 0.5dB deviation) |
| Product Weight | 12.7 OUNCES (0.794 LBS) |
| Product Length | 180 MM (7.09 IN) |
| Product Width | 180 MM (7.09 IN) |
| Country of Origin | Germany |
| Other Information | Product Depth:: 50mm |
You must be logged in to post a review.
Manuals/Guides
| Dimensions | 180 × 180 in |
|---|
