Additel ADT260EX – Handheld Multichannel Reference Recorder, Compound Pressure

• Compound pressure range to -15 to 10,000 psi
• Measurement accuracy of 0.05% and 0.02%FS (model dependent)
• Up to 8 measurement channels
• ATEX certified intrinsically safe
• Field switchable pressure module ADT158EX

The Additel 260Ex is an intrinsically safe handheld multichannel reference recorder with 8 different channel configurations. This Additel versatile and capable handheld, technicians are now able to measure and collect data for pressure, temperature (RTD probes available), barometric pressure and electrical measurement all in one highly portable device. The powerful logging capability and high-level of intrinsic safety make the ADT260Ex the perfect companion for use in the pipeline industry by supporting hydrostatic pressure testing, air leak testing, inlet and outlet pressure testing at pump stations, safety valve and ex-proof membrane testing, wellhead pressure testing, pipeline filter testing, differential pressure transmitter/flow computing testing, as well as routine calibration of pressure devices.

The user-friendly Additel 260EX has a 4.4in color display that can be used in direct sunlight and is backlit for low light spaces. The Additel 260EX has 4, 5, 6 digit resolution with a smartphone like interface.

Features include:

• Datalogging with real-time graphical trending
• Bluetooth and USB communications; Additel’s Link mobile App
• Built-in barometer with accuracy of 55 Pa
• Supports hydrostatic testing
• Fully temperature compensated

Intrinsically Safe

The ADT260EX has passed the most stringent ATEX, IECEX, CSA, and UKCA intrinsic safety certifications. Each unit complies with a certification level of Ex ia IIC T4 Ga. This highly qualified reference recorder can be widely used in potentially explosive gas environments, such as oil and gas platforms, refineries, chemical and petrochemical plants, pharmaceutical industry, energy and gas processing industry.

Datalogging Capabilities

The Additel 260EX includes a sizable built-in automatic recording capability which supports multi parameter logging, trend curve display, local curve observation and statistical feedback. The logged results are stored onboard and can be viewed locally. The data storage capacity is up to 10 million readings (single channel) with a logging interval that is configurable from 0.1s to 9999s.

8 Channels Data Recorder

• Pressure – Built-in module x 1; External module x2; Built-in barometer x1
• Temperature – RTD x2
• Electrical – Measures current, voltage, frequency, loop power, pulse or switch testing x 1
• Simulated – Differential pressure
