AEMC 6503 – Megohmmeter (Hand-cranked, 250V, 500V, 1000V) – Catalog #: 2126.52
16 people are viewing this product right now
Original price was: $670.00.$636.50Current price is: $636.50.
Shipping calculated at checkout.
Estimated delivery:5 days
Megohmmeter Model 6503 (Hand-cranked, 250V, 500V, 1000V) – Catalog #: 2126.52
- True Megohmmeter
- Test voltages of 250V, 500V, and 1000V
- Insulation measurements to 5000MO
- Led indicates constant voltage output and proper cranked speed controlled by a voltage regulator
- Automatic discharge when the measurement is finished
- Auto-Ranging – dual scale operation for better sensitivity and easier readings
- Compact self-contained package; folded cranked
- Voltage displayed prior to, during and at the end of the test
- Large direct reading scale
- EN 61010-1, 600V CAT II, 300V CAT III
Guarantee Safe and Secure Payment Checkout
Description
AEMC 6503
- True Megohmmeter
- Test voltages of 250V, 500V, and 1000V
- Insulation measurements to 200 and 5000Ω
- Led indicates constant voltage output and proper cranked speed controlled by a voltage regulator
- Automatic discharge when the measurement is finished
Megohmmeter (Hand-cranked, 250V, 500V, 1000V) – Catalog #: 2126.52
The Megohmmeter Model 6503 is a compact, self-contained, hand-cranked True Megohmmeter®. This practical and dependable instrument is designed for a broad range of plant and field service applications, such as acceptance testing and preventive maintenance of wiring, cables, switchgear and motors. The easy hand-cranked operation provides a steady, DC voltage output across the entire range for consistently reliable readings. The Model 6503 has three test voltages for insulation resistance testing: 250V, 500V and 1000V. Test voltages are generated in full across the entire measurement range.
Applications
- Continuity checks
- Test motors, cables, switchgears and electrical wiring installations
- Acceptance testing and preventive maintenance
- Check domestic and industrial wiring
Micro / Milli / Meg Ohmmeters/Megohmmeter / Insulation Resistance Testers Template | |
|---|---|
| IR Test Voltage | 1,000 V, 250 V, 500 V |
| Maximum Insulation Resistance | 5000 M Ohms (5 G Ohms) Maximum Insulation Resistance 250V 1Ω to 11MΩ, 11Ω to 500MΩ |
| Type | Hand Crank |
| Minimum Insulation Resistance | 1 M Ohms (0.001 G Ohms) |
| Variable Incremental Voltage | No |
| Display (Megohmmeter) | Analog |
| Continuity Test | No |
| Live Circuit Voltage Detection | No |
| Timer | No |
| CAT Rating | III |
| CAT Voltage | 300 V, 600 V CAT Voltage 300V CAT III; 600V CAT II |
Product General Attributes | |
| Unique Features | LED indicates constant voltage output and proper cranked speed Automatic discharge when measurement is finished Auto-Ranging – dual scale operation for better sensitivity and easier readings Designed for harsh environments: marine, mining, heavy-duty field, industrial and military use Case; O-ring sealed against rain, water and dust; aluminum lid Compact self-contained package; folded crank Large direct-reading scale no batteries needed |
| Warranty | 1 YEARS |
| Safety Approval | CE |
| IP Rating | IP54 IP Rating IP54 with cover and IP52 without (IEC 60529 Ed. 92) |
| Product Weight | 2.5 LBS |
| Product Height | 5.3 IN |
| Product Length | 4.7 IN |
| Product Width | 4.4 IN |
| Data Logging | No |
| HTS/Schedule B Number | 9030.33.3400 |
| ECCN Number | EAR99 |
| Calibration Included | Factory Calibration |
| Battery Type | Other |
| Country of Origin | China |
| UPC | 685338150216 |
You must be logged in to post a review.
Manuals/Guides
| Weight | 2.5 lbs |
|---|---|
| Dimensions | 4.7 × 4.4 × 5.3 in |
