Amblyonix 3010A – Megohmmeter, 10 kV
15 people are viewing this product right now
$2,799.00
Shipping calculated at checkout.
Estimated delivery:3 days
Megohmmeter 10 kV
- Test Voltage Range: 250V, 500V, 1000V, 2500V, 5000V, 10kV
- DC Voltage Range: 0 to 1000V
- AC Voltage Range: 0 to 750V
- Ultra-lightweight, powerful, and designed for field use
- Large format LCD with adjustable back lighting
- Adjustable alarm function
- On-board memory stores 500 test results
- Front-panel USB communication interface
- Rugged aluminum case for instrument and accessory storage
- 1-year parts and labor warranty
Guarantee Safe and Secure Payment Checkout
Description
Amblyonix 3010A
- Test Voltage Range: 250V, 500V, 1000V, 2500V, 5000V, 10kV
- DC Voltage Range: 0 to 1000V
- AC Voltage Range: 0 to 750V
- Ultra-lightweight, powerful, and designed for field use
- Large format LCD with adjustable back lighting
Megohmmeter, 10 kV
The Amblyonix 3010A Megohmmeter features test voltage range from up to 10 kV.
Remarkably light-weight, compact, and extremely portable, the Amblyonix 3000A series of industrial megohmmeters are designed to provide years of dependable service. Powered by advanced Lithium-ion battery technology, these megohmmeters are able to perform hundreds of insulation resistance tests from a single charge. All models have a large-format liquid crystal display with adjustable backlighting. Measurements and test routines are clearly displayed and can be stored or exported for future analysis. Selectable timer functions are easily programmable for measuring dielectric absorption ratios and polarization indexing. Equipped with strong anti-interference circuit architecture, they are ideally suited for substation testing applications.
3000A Series Comparison Table
| Model Number | Test Voltage Ranges | Test Voltage Accuracy | Short Circuit Current |
| Amblyonix3010A | 250V, 500V, 1000V, 2500V, 5000V, 10kV | ±10% | ≥5mA@10kV |
| Amblyonix3015A | 500V, 1000V, 2500V, 5000V, 10kV, 15kV | ±10% | ≥6mA |
| Amblyonix3005A | 100V, 250V, 500V, 1000V, 2500V, 5000V | ±10% | ≥5mA@5kV |
Micro / Milli / Meg Ohmmeters/Megohmmeter / Insulation Resistance Testers Template | |
|---|---|
| IR Test Voltage | 1,000 V, 10,000 V, 2,500 V, 250 V, 5,000 V, 500 V |
| Display (Megohmmeter) | Digital |
| Power Supply | Battery |
Product General Attributes | |
| Warranty | 1 YEARS |
| Warranty Details | All products are covered with a 1 year parts and labor warranty. |
| Product Weight | 6 LBS |
| Product Height | 6 IN |
| Product Length | 10.9 IN |
| Product Width | 9 IN |
| Battery Type | Li-ion |
| Power Supply Voltage | Battery Powered |
You must be logged in to post a review.
Manuals/Guides
Spec Sheets
| Weight | 6 lbs |
|---|---|
| Dimensions | 10.9 × 9 × 6 in |
