Ashcroft ATE-2 ST – Hand Held Pressure and Temperature Calibrator
34 people are viewing this product right now
Original price was: $2,364.73.$2,208.65Current price is: $2,208.65.
Shipping calculated at checkout.
Estimated delivery:5 days
Hand Held Pressure and Temperature Calibrator
- Data logging up to 16k records
- IP65 / NEMA 4X enclosure
- SD memory card slot
- USB interface
- Large back lit display
- 180 Degree flip display
- Percent error function
- Tare function
- Onboard 24Vdc loop power supply (non-intrinsically safe version)
- Push-button zero adjust
Guarantee Safe and Secure Payment Checkout
Description
Ashcroft ATE-2 ST – Hand Held Pressure and Temperature Calibrator
The Ashcroft® ATE-2 ST handheld digital calibrator is a portable, multifunction instrument performing precision measurement of pressure, temperature, current, or voltage. The base unit includes application-specific firmware for the convenient calibration and setting of measurement and control devices, as well as logging of associated data. In addition, the ATE-2 ST has the ability to interface with a computer, data acquisition system, or terminal emulator via the standard USB interface. An ideal instrument when precision calibration and traceability are required.
Process / Calibration/Multifunction Calibrators Template | |
|---|---|
| Type | Hand Held |
| Measure Voltage | Yes |
| Simulate Loop Voltage | No |
| Voltage Measurement Max | 30 V |
| Voltage Measurement Min | 0 V |
| Source/Simulate DC Current | No |
| Measure DC Current | No |
| Current Measurement Max | 20 mA |
| Current Measurement Min | 0 mA |
| Source/Simulate Resistance | No |
| Measure Resistance | Yes |
| Resistance Measurement Max | 4000 Ohms |
| Source/Simulate Frequency | No |
| Measure Frequency | No |
| Measure RTD | Yes |
| Measure Thermocouples | Yes |
| Source/Simulate Pressure | No |
| Pressure Measurement | Dual Pressure Sensor |
| Pressure Modules Available | Yes |
| Hart Compatible | No |
| FieldBus Compatible | No |
| Data Log Functions | Temperature Data Log Functions Pressure |
| Backlighted | Yes |
| Graphical Screen | No |
| Types RTD/Thermocouples Accepted | B, E, J, K, N, PT100 RTD, PT1000 RTD, R, S, T |
| Intrinsically Safe(Calibrators) | No |
Process / Calibration/Pressure Calibration/Pressure Calibrators Template | |
| Backlight | Yes |
Product General Attributes | |
| Unique Features | Pressure and temperature hand held calibrator with two ports for hot-swappable Quick-Select pressure and temperature modules. Wide selection of modules. 24 VDC loop power supply built in (non-I.S. intrinsically safe version). Datalogging capability. |
| Safety Approval | CE, RoHS, UL |
| Interfaces I/O | USB |
| Storage | SD Card |
| IP Rating | IP65 |
| Product Weight | 2.4 LBS |
| Shipping Weight | 5 LBS |
| Data Logging | Yes Data Logging • Internal storage for up to 64 data logs and up |
| HTS/Schedule B Number | 9026204000 |
| ECCN Number | EAR99 |
| Calibration Included | NIST Calibration |
| Battery Type | AA Battery Type (4) AA. 40 hr battery life with two modules installed |
| Power Supply Voltage | Battery Powered Power Supply Voltage (4) AA Batteries |
| Country of Origin | United States |
