Associated Research 07715 – AC Hipot Tester, 20 kV @ 10 mA AC
27 people are viewing this product right now
$10,228.90
Shipping calculated at checkout.
Estimated delivery:5 days
20 kV @ 10 mA AC Hipot Tester
- HypotMAX series
- High voltage AC hipot tester
- 20 kV @ 10 mA AC
- Automate tests via PC
- Intuitive user interface
- Smart GFI protects users from high voltage
- Remote Safety Interlock helps create a safe workstation with DUT enclosure and light curtain
- Includes Free NIST-Traceable Calibration Certificate
Guarantee Safe and Secure Payment Checkout
Description
Associated Research 07715
- HypotMAX series
- High voltage AC Hipot tester
- 20 kV @ 10 mA AC
AC Hipot Tester, 20 kV @ 10 mA AC
The Associated Research HypotMAX Series is a complete line of automated Hipot instruments designed to meet the demanding requirements of high-voltage applications. Associated Research has included its patented SmartGFI feature for maximum operator safety, as well as a variety of advanced features to increase productivity on the production line and in the lab. Set up and run tests with confidence from the intuitive user interface or automate with a PC.
The HypotMAX is available in both AC and DC formats:
| AC Hipot | DC Hipot | |
| 07705 | • | |
| 07710 | • | |
| 07715 | • | |
| 07720 | • |
The maximum voltage for each unit is as follows:
- 07705 – 10 kV @ 20 mA AC
- 07710 – 12 kV @ 10 mA DC
- 07715 – 20 kV @ 10 mA AC
- 07720 – 20 kV @ 5 mA DC
Safety & Productivity Features
Safety Testing / Surge Testing/Hipot Tester Template | |
|---|---|
| Test Type Hipot | AC |
| Max AC Test Voltage | 20 kV |
| Max Trip Current AC Test | 10 mA |
Product General Attributes | |
| Product Weight | 48.9 LBS |
| Product Height | 5.24 IN |
| Product Length | 15.75 IN |
| Product Width | 16.93 IN |
| Shipping Weight | 53 LBS |
| Calibration Included | NIST Calibration |
| Country of Origin | Taiwan |
You must be logged in to post a review.
Manuals/Guides
| Weight | 48.9 lbs |
|---|---|
| Dimensions | 15.75 × 16.93 × 5.24 in |
