B&K Precision 9141 – Triple Output Multi-Range DC Power Supply, 300W/60V/4A
37 people are viewing this product right now
$2,134.00
Shipping calculated at checkout.
Estimated delivery:4 days
Triple Output DC Power Supply 60V/4A, 300W
- Three independent, floating output channels for up to 100 W per channel or 300 W total
- 60V Max Output Voltage per channel
- 4A Max output current per channel
- High power density, compact 2U half-rack form factor
- Low output ripple and noise down to 1 mVrms
- Advanced and easy to use list mode programming
- Channel coupling, tracking, configurable delays
- Direct data logging to USB flash drive
- Thermostatically-controlled fans for quiet operation
- Adjustable voltage and current slew rates
Guarantee Safe and Secure Payment Checkout
Description
BK Precision 9141
- Three independent, floating output channels for up to 100 W per channel or 300 W total
- 32V Max Output Voltage per channel
- 8A Max output current per channel
- High power density, compact 2U half-rack form factor
- Low output ripple and noise down to 1 mVrms
Triple Output Multi-Range DC Power Supply, 300W/60V/4A
The 9140 Series triple output multi-range DC power supplies combine industry-leading power density and performance with an extensive set of features in a compact 2U form factor. Three isolated output channels each produce 100 W of clean power with low ripple and noise characteristics. Combine channels for up to 300 W total output power.
Powerful list mode programming enables users to set up and execute complex test sequences directly from the front panel. Multiple outputs, USB data logging, and comprehensive protection features make these power supplies suitable for a wide range of benchtop or test system applications.
This series provides system integrators with a LXI compliant LAN, USB (USBTMC-compliant), and optional GPIB interface for remote control and programming. The provided LabVIEWTM, IVI-C, and IVI.NET drivers further simplify system development and integration. In addition to OVP, OCP, and OTP protections, these power supplies support remote inhibit and voltage fault features to protect both the device under test (DUT) and the power supply
| Model | 9140 | 9140-GPIB | 9141 | 9141-GPIB |
| Voltage per Channel | 0 to 32V | 0 to 32V | 0 to 60V | 0 to 60V |
| Current per Channel | 0 to 8A | 0 to 8A | 0 to 4 A | 0 to 4 A |
| Maximum Output Power per Channel | 100W | 100W | 100W | 100W |
| Maximum Combined Output Power | 300W | 300W | 300W | 300W |
| GPIB | No | Yes | No | Yes |
Power Supplies/DC Power Supplies Template | |
|---|---|
| Outputs | Triple |
| Voltage Output 1 | Variable |
| Max Voltage Output 1 | 60 V |
| Current Output 1 | Variable |
| Max Current Output 1 | 4 A |
| Max Display Resolution Current | 1 mA |
| Max Display Resolution Voltage | 1 mV |
| Constant current/voltage | Yes |
| Remote Sensing | Yes |
Product General Attributes | |
| Warranty | 3 YEARS |
| Safety Approval | CSA, UL |
| Interfaces I/O | LAN / Ethernet, USB |
| Storage | Internal Memory |
| Product Height | 3.5 IN |
| Product Length | 13 IN |
| Product Width | 8.4 IN |
| Shipping Weight | 13 LBS |
| HTS/Schedule B Number | 8504.40.9530 |
| ECCN Number | 3A992 |
| Calibration Included | Factory Calibration |
| Country of Origin | Taiwan |
You must be logged in to post a review.
Manuals/Guides
Spec Sheets
| Dimensions | 13 × 8.4 × 3.5 in |
|---|
