Description
BW Gas Alert Quattro Multi-Gas Detector (Up To 4 Gases) – Product Selection Tool
Rugged and reliable, the GasAlert Quattro four-gas detector combines a comprehensive range of features with simple one-button operation. With flexible power options, the GasAlertQuattro is always ready. The graphic LCD displays easy-to-identify icons that indicate operational information, such as bump test and calibration status for simplified on-site auditing. IntelliFlash provides continuous visual confirmation of detector operation and compliance. Suited to a wide range of industrial applications including confined space entry, the GasAlert Quattro is fully compatible with BW’s MicroDock II automatic test and calibration system.
The GasAlert Quattro meets ACGIH 1 ppm H2S TWA recommendations.
Easy auditing
No manual checks, no time spent inspecting… just a quick visual scan of the area provides assurance all is well in minutes, not hours. So safety managers can spend more time on the job, not auditing equipment.
The green LED confidence flash verifies normal operation, including bump test and calibration compliance, to both the user and supervisors from up to 20 ft. / 6.10 m.

Compatible with MicroDock II (optional)
The BW Quattro is also compatible with the MicroDock II automatic test and calibration station.
The MicroDock II is an easy, cost-effective way to bump-test, calibrate, charge and manage records for BW portable gas detectors. With Fleet Manager II software, download information faster than ever from the MicroDock II. Improved functionality allows you to create accurate and user-friendly reports, print receipts of calibration, sort and graph data, archive information and manage your fleet of detectors. Compliance has never been easier.


Gas Detection/Personal Gas Detection Template | |
|---|---|
| Number of Gases | Multi |
| Gas Types | CO, H2S, LEL, O2 |
| Alarm (Personal Gas Detector) | Audible-Visible-Vibrating |
| Type (Gas Detection) | Portable |
| CO | Yes |
| H2S | Yes |
| O2 | Yes |
| LEL | Yes |
| Min Measurement Range CO | 0 PPM |
| Min Measurement Range H2S | 0 PPM |
| Min Measurement Range O2 | 0 PPM |
| Min Measurement Range LEL | 0 % |
| Max Measurement Range CO | 1000 PPM |
| Max Measurement Range H2S | 200 PPM |
| Max Measurement Range O2 | 30 % |
| Max Measurement Range LEL | 100 % |
Product General Attributes | |
| Warranty | 2 YEARS |
| Warranty Details | Full two-year warranty including all sensors |
| Safety Approval | ATEX, CE, CSA, IECEx |
| Product Weight | 11.15 OUNCES (0.697 LBS) |
| Product Height | 13 IN |
| Product Length | 8.1 IN |
| Product Width | 4.7 IN |
| Battery Type | AA, Other |
