Com-Power AH-220 – MIL-STD Double Ridge Horn Antenna, 200 MHz to 2000 MHz
26 people are viewing this product right now
$12,045.00
Shipping calculated at checkout.
Estimated delivery:4 days
Horn Antenna, 200 MHz to 2000 MHz
- Broadband: 200 MHz to 2 GHz
- Transmit and receive capabilities
- Individual calibration
- Three year warranty
- 800 Watts of CW Power Handling
Guarantee Safe and Secure Payment Checkout
Description
Com-Power AH-220
- Frequency Range 200 MHz to 2 GHz
- Transmit and Receive Capabilities emissions/immunity applications
- Individual Calibration Included per SAE ARP958 with NIST traceability
- Three-year Standard Warranty
MIL-STD Double Ridge Horn Antenna, 200 MHz to 2000 MHz
The AH-220 is a broadband, linearly polarized Double Ridge Waveguide Horn Antenna, operating over the frequency range of 200 MHz to 2 GHz. While it is designed to serve as the receiving antenna for radiated emissions tests between 200 MHz and 1 GHz, as specified within RE102 of MIL-STD-461, it can also be used as a transmitting antenna for radiated immunity tests.
Construction
The AH-220, due to its large size, is designed to be as lightweight an antenna as possible, without sacrificing its overall durability. The antenna is constructed using high grade aluminum with a corrosion resistant conductive coating. The antenna is fitted with a high quality N-type coaxial connector.
Accessories/Antennas Template | |
|---|---|
| Maximum Frequency Range | 2 GHz (2000 MHz) |
Product General Attributes | |
| Product Weight | 29.5 LBS |
| Product Height | 37 IN |
| Product Length | 27.2 IN |
| Product Width | 37.2 IN |
| Shipping Weight | 160.00 LBS |
You must be logged in to post a review.
Manuals/Guides
ManualsSpec Sheets
| Weight | 160 lbs |
|---|---|
| Dimensions | 27.2 × 37.2 × 37 in |
