Comet T3110 – Temperature and Humidity Outdoor, Indoor Probe with 4-20mA Output

• Equipped with temperature and relative humidity sensors
• Measured values are also converted to other humidity interpretation
• Dew point temperature
• Absolute humidity

Programmable temperature and humidity transmitter is equipped with temperature and relative humidity sensors. Measured values are also converted to other humidity interpretation – dew point temperature, absolute humidity, specific humidity, mixing ratio, or specific enthalpy. Degrees Celsius and Fahrenheit are user selectable. Transmitter contains a microprocessor-based control circuitry in a durable plastic case with connection terminals and sensors in a filter with stainless steel mesh. Transmitters are available with two 0-10V outputs. Configuration of outputs and output range are user adjustable. Large dual line LCD for simultaneous display of T+RH or other humidity interpretation is an advantage. Display is possible to switch off. Computerized design ensures temperature compensation of the humidity sensor and fails indication. State-of-the-art capacitive polymer sensor ensures excellent calibration long-term stability, inertia against water, and condensation. Transmitters are designed for use in non-aggressive environment.

Applications – Measuring and Control of Air Humidity

• Warehouses
• Air-conditioned rooms
• Glasshouses
• Manufacturers
• Weather stations
• Museums, archives, galleries
• Building HVAC Management/Automation

Transmitters are approved and homologated by RENAULT and by PSA (PEUGEOT / CITROEN) car manufacturers. Any measured value – temperature, relative humidity, dew point temperature, absolute humidity, specific humidity, mixing ratio, or specific enthalpy can be assigned to each output of dual output transmitters. Also, identical values can be assigned to both outputs.
