Digilent myProto – Protoboard for NI myDAQ and myRIO

• Access all your myDAQ’s signals on a breadboard
• Three onboard user LEDs
• One 10K Potentiometer
• Two Audio Jacks
• External power connector for breadboard circuits

The Digilent myProto accessory board for NI myDAQ attaches directly to the myDAQ and brings all myDAQ signals to breadboard connections where they can be easily accessed using simple jumper wires. The myProto also includes several additional useful I/O devices. Signal names on the myProto breadboards indicate which myDAQ signals and onboard devices are attached to which breadboard pins. All Ground connections on the myProto breadboards are connected into a single Ground node on the myProto device.
