Dwyer 422-10 – Inclined/Vertical Manometer
42 people are viewing this product right now
$1,804.40
Shipping calculated at checkout.
Estimated delivery:3 days
Inclined/Vertical Manometer
- Inclined/vertical manometer, inclined range: 0-1.0″ w.c., .01 min. div., 6-1/2″ scale; vertical range 1.1-10″ w.c., min. div. .10, 10-1/8″ scale.
- 1-1/4″ Thick Acrylic Plastic Body is a solid block, virtually unbreakable, stable and absolutely free of the danger of distortion
- 3/16″ Bores, Accurate to ± .0002″ are permanently free of bends or crooks, will not require recalibration because of distortion
- Ground Glass Bubble Level sensitive to 115-125 sec./2 MM. is 1-1/2″ long x .375″ diameter and provided with two red lines for easy visibility and alignment
- Parallax-Free Reading for maximum accuracy and consistency is achieved by simply aligning the meniscus with its image reflected in the polished aluminum scale
- Selected Gage Fluid with high wetability characteristics forms a consistent, well shaped meniscus for perfect readability
- O-Ring Sealed Fluid Level Plunger Adjustment for easy zeroing
- Precision Built to assure device meets the highest standards
- High-accuracy measurement of low range gas and air pressure suitable for laboratory and test applications
- Long bore length provides ample room for fluid movement for low range sensing
Guarantee Safe and Secure Payment Checkout
Description
Dwyer 422-10
- Inclined range: 0-1.0″
- Vertical range: 1.1-10″
- Precision is built to assure the device meets the highest standards
- High-accuracy measurement of low-range gas and air pressure suitable for laboratory and test applications
Inclined/Vertical Manometer
Dwyer Series 424 & 420 inclined-vertical manometers are extremely accurate instruments designed and made especially for precision measurement of low differential pressures in laboratory and test applications. The inclined range bore has a length of 20″ to provide amp. Precision is built to assure the device meets the highest standards.
HVAC Equipment and Instruments/Manometer Template | |
|---|---|
| Type (Manometer) | Inclined Tube Type (Manometer) Vertical |
| Max Pressure | 10 IN of H2O |
| Engineering Units (HVAC) | inch H2O |
| Measurement | Differential |
Product General Attributes | |
| Unique Features | • Inclined range: 0-1.0″ w.c. • Vertical range 1.1-10″ w.c. |
| Warranty | 1 YEARS |
| Warranty Details | The Seller warrants all Dwyer Instruments and equipment to be free from defects in workmanship or material under normal use and service for a period of one year from date of shipment. Liability under this warranty is limited to repair or replacement EXW Ex Works Dwyer Instruments, Inc. of any parts which prove to be defective within that time or repayment of the purchase price at the Seller’s option provided the instruments have been returned, transportation prepaid, within one year from date of purchase. All technical advice, recommendations and services are based on technical data and information which the Seller believes to be reliable and are intended for use by persons having skill and knowledge of the business, at their own discretion. In no case is Seller liable beyond replacement of equipment EXW Ex Works Dwyer Instruments, Inc. or the full purchase price. This warranty does not apply if the maximum ratings label is removed or if the instrument or equipment is abused/altered. |
| Product Weight | 22.75 LBS |
| Country of Origin | United States |
You must be logged in to post a review.
| Weight | 22.75 lbs |
|---|
