ETI PI-250 Gen2 – Portable Circuit Breaker Test Set – Peak Output 1000A

• Peak output of 1000A (Ranges: 10, 25, 50, 100, 250, 500, 1000A)
• Ideal for testing circuit breakers, motor overload relays, and ground fault trip devices
• Housed in a rugged enclosure that weighs no more than 44 pounds
• Enhanced cooling and ventilation system to minimize “off” times between tests
• High accuracy readings of true-RMS continuous and pulse current

The PI-250 Gen2 Circuit Breaker Test set is housed in a lightweight, rugged case for maximum portability and durability. This tester has been designed and built with a focus on reliability and ease of use.

• Peak Output of 1000A: This test set achieves peak output of approximately 1000A, making the unit ideal for testing circuit breakers, motor overload relays, and ground fault trip devices, whether magnetic, thermal, or solid-state.
• Built For Field Service: The PI-250 Gen2 test set is housed in a rugged enclosure that weighs no more than 44 pounds, allowing one-person easy mobility.
• Maximize Testing Productivity: The PI-250 Gen2 uses an enhanced cooling and ventilation system to minimize “off” times between tests. It offers high accuracy readings of true-RMS continuous and pulse current along with reliable current latch mode operation and timing accuracy.
• Prioritizing Safety: Improved Cam-Lok output connectors help ensure a secure connection.

Applications

The perfect test set for every service vehicle in your fleet. This high current test set is designed with high current, low voltage outputs used for many purposes, including primary injection testing of direct-acting low voltage circuit breakers, motor overload relays, current transformers and heat run. The front panel displays provide simple indication of output current, time, and system status. The keyboard provides easy control of output.
