Description
Fluke 773 Milliamp Process Clamp Meter
- Measures mA Signals for control systems, PLC systems, Analog input output without breaking the loop!!
- Can measure the output signals from transmitters without breaking the loop.
- Comes with detachable clamp. This comes in very handy for tight locations.
Need more hours in your day?
Save time by NOT breaking the loop on 4-20 mA signal measurements.
Are you spending time:
- Taking mA measurements by removing a wire and breaking the loop
- Calling the control room to isolate a loop
- Testing analog input/output on a console
- Troubleshooting devices with mA inputs and outputs
- Repairing intermittent or erratic 4-20 mA loops
- Going back to the shop to get extra tools
If you need more time in your busy day take a good look at the Fluke 773 mA Clamp Meters. It’s designed to save you time, and money, by eliminating time wasting activities. Now you can troubleshoot and repair 4-20 mA loops without breaking the loop or bringing down the system.
Here are some specific ways the Fluke 773 Clamp Meters will help you:
Milliamp Clamp Features | Application | How it saves time and money |
Measure mA signals for PLC and control system analog I/O without breaking the loop. | Measures low level dc current | Correlate process indication with real physical value |
Measure output signals from transmitters without breaking the loop | Maintain and troubleshoot process and automation equipment without breaking the loop | No disruption to the process |
Detachable clamp with extension cable | Measurements in tight locations | Enables measurements in difficult situations |
Source, simulate and measure mA signals in circuit (break the loop) | Confirm non-contact measurement. ve the next tool in hand for troubleshooting (source simulate) | Eliminates the need to return to the shop to get a loop calibrator for troubleshooting after finding a bad signal with non-contact measurement |
Source and measure VDC | Troubleshoot voltage input and output devices | Measure presence of 24V loop power. Measure 1 to 5 or 0 to 10V process signals. Test chart recorders |
4 to 20 mA In/out | Dual channel mA source and measurement for troubleshooting | Source 4 to 20 mA signals into valves and mA signal conditioners and simultaneously measure 4 to 20 mA positioning output signals |
4 to 20 mA scaled output | Scaled mA output provides a mA signal output representative of the measured mA value | Connect a logging DMM and log the mA signal without breaking the loop |
Loop power supply | Power a transmitter | Substitute testing of the installed 24V loop power supply. Power a transmitter and measure its mA output signal for troubleshooting |
Dual backlit display with both mA measurement and percent of 4 to 20 mA span | Clear measurement presentation | Allows quick measurement evaluation |
Measurement Spotlight | Illuminates hard to see wires in dark enclosures | Measurement process is easier and quicker |
Measure up to 99.9 mA range non-contact | Wide range of measurements | Measures 10 to 50 mA signals in older control systems |
Automatic power off | After 15 minutes and 2 minute automatic off for backlight and spotlight | Saves battery life |
Fluke-771 | Fluke-772 | Fluke-773 | |
Non-contact mA loop measurement | Integrated mA loop troubleshooting | Advanced process troubleshooting | |
mA measure, jaw | • | • | • |
mA measure, in circuit | • | • | |
Loop power | • | • | |
mA source | • | • | |
DCV measure | • | ||
DCV source | • | ||
mA scaled output | • | ||
mA in / out | • |
Clamp Meters/Clamp Meters Template | |
---|---|
True RMS | No |
Maximum Current DC | 100 mA (0.1 A) |
Maximum Voltage DC | 30 V |
Maximum Conductor Size | 0.177 IN |
Resistance | No |
Capacitance | No |
Auto Ranging/Manual | Manual |
In-Rush Current | No |
Process / Calibration/Signal Calibrators/Loop Calibrators Template | |
Measure Inputs | Yes |
Source Outputs | Yes |
Maximum Current | 99.9 mA (0.100 A) |
Current Measurement Resolution | 0.01mA |
Current Accuracy | 0.2% |
Maximum Voltage | 30 V |
Hart Compatible | No |
Intrinsically Safe | No |
Process / Calibration/Milliamp Calibrators Template | |
Source/Simulate DC Current | Yes |
Measure DC Current | Yes |
Two Wire Transmitter Simulation | Yes |
Percent Display | Yes |
Accuracy | 0 to 20.99 mA: 0.2%+2 counts 21.0 mA to 100.0 mA: 1%+5 counts |
Simulate Loop Voltage | Yes |
Backlight | Yes |
Ramp/Step Output | Yes |
Battery Life | 12 HR |
FieldBus Compatible | No |
Product General Attributes | |
Unique Features | DC voltage measurement to verify 24 V power supplies or voltage I/O signals. Source dc voltage to test input devices that accept a 1 to 5 volt or 0 to 10 volt signal. mA in/out: simultaneously measure the mA signal with the clamp and source a mA signal – Apply a mA input signal to a device and measure its’ 4 to 20 mA output on devices such as valves or mA isolators. |
Warranty | 3 YEARS |
Warranty Details | One-year on mA clamp assembly and cable. |
IP Rating | IP40 |
Product Weight | 2.38 OUNCES (0.149 LBS) |
Product Height | 2.76 IN |
Product Length | 12.52 IN |
Product Width | 5.87 IN |
Data Logging | No |
Calibration Included | None |
CA Residents | Warning: Cancer and Reproductive Harm – www.P65Warnings.ca.gov |
Battery Type | AA |
Power Supply Voltage | Battery Powered |
Country of Origin | China |
UPC | 095969475822 |
