Description
Fluke 922 was designed and built for how (and where) you do your job, with performance, ruggedness and ease of use, setting the Fluke 922 apart from the competition.
The bright white display and ruggedized holster and wrist strap let you take the Fluke 922 into less than ideal environments. The color-coded hoses help you keep track of where your readings are coming from. The simple, intuitive interface means you can measure pressure, velocity, or airflow at the push of a button. The Fluke 922 helps you analyze airflow. Easily.
Analyze Airflow. Easily.
Today’s HVAC technicians want a simple solution for diagnosing ventilation issues. Differential pressure measurements only tell part of the story. Technicians also want to measure air velocity a nd flow, without having to resort to expensive, difficult to use, specialist tools. The Fluke 922 makes airflow measurements easy by combining these tools: differential pressure,airflow, and velocity into a single, rugged meter.
The Fluke 922 Airflow Meter helps you:
- Monitor air pressure across key HVAC components.
- Ensure proper air flow balance.
- Promote good indoor air quality.
- Maintain a comfortable environment.
Use the Fluke 922 Airflow Meter to:
- Measure pressure drops to access key HVAC equipment to drive peak performance and extend equipment life.
- Match ventilation to occupant loads.
- Monitor indoor vs. outdoor pressure relationships and manage the building envelope.
- Promote indoor comfort and quality.
- Perform duct traversals for accurate airflow readings.
Environmental Testers / Physical Property/Anemometer / Air Flow Template | |
|---|---|
| Type (anemometer) | Pitot Tube |
| Measurement (anemometer) | Ft/Min, m/s |
| Air Velocity Max | 16000 ft/min Air Velocity Max 80 m/s |
| Air Velocity Min | 250 ft/min Air Velocity Min 1 m/s |
| Accuracy Air Velocity | ± 2.5 % of reading at 2000 fpm (10.00 m/s) |
| Humidity | No |
| Temperature | Yes |
| IR Sensor for Tempature | No |
| Thermocouple Sensor for Temperature | No |
| Dew Point | No |
| Windchill | No |
| Light Meter | No |
| Water Proof | No |
| Min/Max Display | Yes |
| Data Hold | Yes |
| Thermal Printer Option | No |
| Interchangable Probe Options | Yes |
| Replaceable Vane | No |
| Metal Vane | No |
HVAC Equipment and Instruments/Manometer Template | |
| Type (Manometer) | Digital |
| Max Pressure | 400 MM of H2O (7784585.72 IN of H2O) |
| Type of Input | Dual |
| Engineering Units (HVAC) | inch H2O, mmH2O, psi |
| Measurement | Differential, Gauge |
| Min/Max/Hold | Yes |
| Pressure and Leak Test Option | No |
| Anemometer Capability | Yes |
| Altitude Capability | No |
Product General Attributes | |
| Unique Features | Powerful meter provides differential and static pressure, air velocity and flow readings. User-defined duct shape and size for maximum airflow accuracy. Min/Max/Average/Hold functions for easy data analysis. Data Storage: 99 readings. |
| Warranty | 2 YEARS |
| IP Rating | IP40 |
| Product Weight | 1.52 LBS |
| Product Height | 2.99 IN |
| Product Length | 10.83 IN |
| Product Width | 6.1 IN |
| Data Logging | No |
| Calibration Included | Factory Calibration |
| Battery Type | AA |
| Power Supply Voltage | Battery Powered |
| Country of Origin | Taiwan |
| UPC | 095969355315 |
