Fotric TK7-L49 – Industrial Grade Thermal Camera (384 x 288 Resolution)
41 people are viewing this product right now
$1,648.90
Shipping calculated at checkout.
Estimated delivery:5 days
Thermal imager for smartphone: 384X288 IR Resolution, Manual Focus, 40mK thermal sensitivity, 49 degree wide angle lens
- Resolution: 384 x 288 (Super resolution: 768 x 576)
- Temperature range: -20 to 350 °C
- Field of View: 49° x 36.8°
- Thermal sensitivity: 40mk(0.04 °C)@30 °C
- 30 Hz refresh rate
- TEF-Fusion: 0 – 100% adjustable transparency
- Touch span to highlight the anomaly against the environment
- Take video and images and store on 32GB TF (TransFlash) card
- 3.5” LCD touchscreen
- Dust and water-resistant (IP54), made for durability and industrial adaptability
Guarantee Safe and Secure Payment Checkout
Description
Fotric TK7-L49
- Resolution: 384 x 288 (Super resolution: 768 x 576)
- Temperature range: -20 to 350 °C
- Field of View: 49° x 36.8°
- Thermal sensitivity: 40mk(0.04 °C)@30 °C
- 30 Hz refresh rate
Industrial Grade Thermal Camera (384 x 288 Resolution)
The TK7-L49 is an 8MP industrial-grade thermal camera. It features manual focus, has a 40mK thermal sensitivity, and a 49 x 36-degree wide-angle lens. The camera has a thermal resolution of 384 x 288 pixels and a super resolution of 768 x 576.
Large, 3.5” LCD touchscreen and buttons for clear image and navigation. The imager is IP54 dust and water-resistant and designed for durability and industrial adaptability. The TK7-L49 is powered by Android. The thermal camera features Wi-Fi which supports 1080p video streaming.
Accurate Temperature Measurement
Precision at your fingertips – Perfect focus for flawless temperature readings.
- Manual focus ensures concise measurement at all distances
- 49° wide angle shot, to always see the big picture. Help you infer the root of the thermal anomaly
- 40mk thermal sensitivity, unveil subtle flaws. A damp spot never escapes your sight
Superior Image Quality
- 384 x 288 thermal pixels
- Super resolution, boost the performance to expert level
- TEF-Fusion 0~100% adjustable transparency. Select the best way present your finding
- Touch span to highlight the anomaly against the environment
Thermal Imagers/Building and Industrial Thermal Imagers Template | |
|---|---|
| Detector Size | 384 x 288 Sensor |
| Thermal Sensitivity | 40 mK (NETD) |
| Temperature Range Max | 350 C (662 F) |
| Temperature Range Min | -20 C (-4 F) |
| Image Frequency | 30 Hz |
| Field of View | 49 x 36.8 Degrees |
| Screen Size | 3.5 IN |
| IR/Overlay Fusion Image | Yes |
| Video Output | Yes |
| Focus | Adjustable |
| Laser Spot | Yes |
| Picture in Picture | Yes |
| Video Recording | Yes |
| Touch Screen Display | Yes |
| Minimum Focus Distance | 0.1 M |
| Accuracy | ±2 ° C or 2% , whichever is greater (at 25 ° C ambient temperature） |
| Battery operating time Continuous | 4 HR |
| Voice Annotation | Yes |
| Intrinsically Safe | No |
Product General Attributes | |
| Warranty | 1 YEARS |
| Warranty Details | 1 year warranty on camera, 10 years for IR detector. |
| Safety Approval | RoHS |
| Interfaces I/O | Bluetooth, Wifi, HDMI, USB-C |
| Storage | SD Card |
| IP Rating | IP54 |
| Product Weight | 800 GRAMS (1.76 LBS) |
| Product Height | 243 MM (9.57 IN) |
| Product Length | 142 MM (5.59 IN) |
| Product Width | 95 MM (3.74 IN) |
| Calibration Included | Factory Calibration |
| Battery Type | Li-ion |
| Power Supply Voltage | Battery Powered |
You must be logged in to post a review.
Manuals/Guides
Spec Sheets
| Weight | 800 lbs |
|---|---|
| Dimensions | 142 × 95 × 243 in |
