Gems Sensors 28244 – Electronic Non-Intrinsically Safe Relay, 200 to 250 VAC

• SPST; N.O. Operation, AC or DC models
• Amplify the current handling capability of sensors for controlling high power loads
• Compact; polysulfone bodies are totally encapsulated
• Impervious to shock or vibration
• Solid-state reliability

Gems Sensors solid-state switching units perform the functions of electro-mechanical relays, with the added reliability and advantages inherent in solid-state. Compact, totally encapsulated, and impervious to shock or vibration, these units mount anywhere… even directly on working machinery. LOAD-PAKS®: integrated, solid-state switches that amplify the current handling capabilities of sensors for controlling high power loads. SPST, N.O. operation, AC and DC models. SPDT-PAKS: enable one low-current sensor to control two independent loads up to 5 amps each. Switching is N.O. for one load and N.C. for the other. FLIP-PAKS: provide low-current, “start-stop” or “on-off” switching for industrial motor, liquid level and other control systems. Units hold operational state up to 1/2 second during momentary power loss to cut nuisance shutdowns; low voltage protection is inherent. 120 VAC and 240 VAC models handle loads to 5 amps.
