Global Specialties PB-507 – Advanced Analog & Digital Electronic Design Trainer

• LCD displays the settings from each active module
• USB connection enables viewing and controlling from a PC
• Choose your power source: 6.3/12.6 VAC, 5 VDC or variable ±20 VDC
• Draw power from banana plug connections or the tie-point power supplies above each breadboard bus strip
• Frequency counter module reports on the output of your own specially designed circuits

Global Specialties Circuit Design Trainer, model PB-507, is a powerful, versatile tool for circuit designers, engineers, technicians, students, and hobbyists. All digital controls, USB port, and a wide choice of built-in circuit accessories allow for rapid and accurate construction of virtually any type of analog or digital circuit.

The PB-507’s LCD displays the settings for the active module selected. Simply touch a control element and the LCD switches to that module and displays its settings. Use the USB connection on the PB-507 to control or view the module’s values from a PC. Using this feature you can project the controls to a large viewing screen for a classroom to observe and follow.

The breadboard area is the largest in our trainer family and is removable for easy replacement.

The PB-507 is designed to withstand the toughest treatment. It is constructed with the highest quality components for many years of reliable service. The all-digital circuitry allows for easy function verification and calibration.

The PB-507 is backed by Global Specialties’ industry-leading 3-year warranty.
