Greenlee 657 100″ Reel Stand Spindle
36 people are viewing this product right now
Original price was: $1,295.19.$1,173.89Current price is: $1,173.89.
Shipping calculated at checkout.
Estimated delivery:4 days
SPINDLE, REEL STAND (100 inch )
- 100″ Reel Stand Spindle
- Steel spindles with grooves to fit reel stand rollers
Guarantee Safe and Secure Payment Checkout
Description
Fluke Networks FI1000-LCAPC-TIP LC/APC Bulkhead Video Probe Tip
The Greenlee 687, 683 and 656 Reel Stands and 647, 684 and 657 Reel Spindles are intended for dispensing of cable from cable reels.
- Steel spindles with grooves to fit reel stand rollers
Maintenance Procedure
To maximize efficiency and extend the life of the product, apply a thin coat of grease to the threaded shaft and a moderate amount of grease between the thrust washer and underside of the handle. For best results, apply grease before each use.
To maximize efficiency and extend the life of the product, re-grease the rollers on the reel stand using the grease zerks found in the center of the roller axles.
Before each use apply a generous coat of an extreme pressure lubricant such as a MOLYKOTE G-n type paste to the threaded shaft. Keep the components free of debris.
Reel Stands and Spindles
| Cat. No. | Capacity | Max Height | Base Dimensions | Weight | Max Reel Diameter | Spindle | Capacity | Size | Weight | Max Reel Width |
| 687 | 2500 lb ea (1134 kg) | 28″ (711 mm) | 15″ x 15″ (381 x 381 mm) | 22 lb (10 kg) | 56″ (1422 mm) | 647 | 6000 lb (2722 kg) | Ø2-3/8″ x 62″ (60 x 1575 mm) | 42 lb (19 kg) | 47″ (1194 mm) |
| 683 | 54″ (1372 mm) | 21″ x 24″ (533 x 610 mm) | 40 lb (18 kg) | 96″ (2438 mm) | 684 | 5000 lb (2268 kg) | Ø2-3/8″ x 76″ (60 x 1930 mm) | 50 lb (23 kg) | 61″ (1549 mm) | |
| 656 | 3750 lb ea (1701 kg) | 46-5/8″ (1184 mm) | 23″ x 24.5″ (584 x 622 mm) | 86 lb (39 kg) | 90″ (2286 mm) | 657 | 7500 lb (3402 kg) | Ø3-1/2″ x 100″ (89 x 2540 mm) | 124 lb (56 kg) | 88″ (2235 mm) |
Product General Attributes | |
|---|---|
| Product Height | 4.00 IN |
| Product Length | 100.00 IN |
| Product Width | 4.00 IN |
| Country of Origin | China |
| Shipping Height | 4.00 IN |
| Shipping Length | 100.00 IN |
| Shipping Width | 4.00 IN |
You must be logged in to post a review.
| Dimensions | 100 × 4 × 4 in |
|---|
