HDE DVI-100/K01 – Digital Voltage Indicator 100kV, OH/UG Kit 1

• Measures voltage up to 99kv line-to-ground
• Voltage readout distinguishes between nominal and induced voltages
• Audible indication when voltage is detected
• Test Point mode available (DVI-100T model)
• Auto-shutoff and low battery indication features
• Versatile for overhead and underground applications

Indicates Voltage up to 99kV Kit Built-in self-test to verify proper operation Auto-shutoff with low battery function Powered by a field-replaceable 9V lithium or alkaline battery. No range selector switch or settings are required. Compact, rugged, and lightweight polycarbonate housing Kits are available; contact the factory for details. For use on system voltages up to 161kV (reads up to 99kV line-to-ground) Large auto-ranging LED display indicates the line-to-ground voltage level Audible indication when voltage is detected. Voltage readout allows the user to distinguish between nominal and induced voltage Measure Elbow Test Points with the DVI-100T (underground probe required). Use on overhead lines or in underground applications with a bushing probe. Built-in universal spline for standard hot stick attachment LED’s operates in extreme temperatures Easy-to-read in bright or dark conditions.
