HOBO by Onset T-ACT-0750-050 – Accu-CT Current Transformer 50 Amp/333mV
16 people are viewing this product right now
$86.90
Shipping calculated at checkout.
Estimated delivery:4 days
Accu-CT Current Transformer 50 Amp/333mV
- Revenue-Grade Accuracy, Unprecedented Linearity
- Window Opening 0.75 Inch
- The Accu-CT revenue grade, split-core current transformer offers outstanding linearity and phase angle accuracy with a unique one-handed opening and closing mechanism
- Safe: burden resistor built-in, 333 mVac voltage output at rated full scale current, no shorting blocks needed
- IEEE C57.13 and IEC 60044-1 accuracy: over full temperature range and down to 1% of rated current
- Exceptionally low phase angle error: essential for accurate power and energy measurements
- Glove-friendly: easy to open and install with one hand while wearing safety gloves
- Approvals: UL recognized, CE mark, RoHS
Guarantee Safe and Secure Payment Checkout
Description
HOBO by Onset T-ACT-0750-050
- Revenue-Grade Accuracy, Unprecedented Linearity
- Window Opening 0.75 Inch
- The Accu-CT revenue grade, split-core current transformer offers outstanding linearity and phase angle accuracy with a unique one-handed opening and closing mechanism
- Safe: burden resistor built-in, 333 mVac voltage output at rated full scale current, no shorting blocks needed
- IEEE C57.13 and IEC 60044-1 accuracy: over full temperature range and down to 1% of rated current
Accu-CT Current Transformer 50 Amp/333mV
The Accu-CT revenue-grade, split-core current transformer offers outstanding accuracy and one-handed operation.
Environment:
The T-ACT-0750-050 Sensor is for use in Indoor environments.
Measurements:
The T-ACT-0750-050 Sensor supports the following measurements: AC Current, Amps (A).
Current Sensors/Current Transformers Template | |
|---|---|
| Type (Current Tarnsformers) | Split Core |
| Current Measured | AC |
| Accuracy | ±0.75% from 1% to 120% of rated primary current |
| Phase Shift (Current Transformers) | 30 Degrees |
| Output | Current |
Product General Attributes | |
| Unique Features | 50 Amp Split-Core Current Transformer |
| Safety Approval | CE, RoHS, UL |
| Country of Origin | United States |
