ITech IT6502D – DC Power Supply 80V / 60A 800W
38 people are viewing this product right now
$1,430.00
Shipping calculated at checkout.
Estimated delivery:3 days
DC Power Supply 80V / 60A 800W
- IT6502D 800W DC Power Supply 80V / 60A
- VFD display
- Achieve max. voltage/current within rated power
- High resolution of 1mV, 1mA
- Low noise and ripple, comparable with linear power supply
- Compact, high density, rack mount size
- Built-in USB/RS232/RS485 communication interface
- Master-Slave mode for parallel and series operation
- With standard SCPI communication protocol
- Analog control interface
Guarantee Safe and Secure Payment Checkout
Description
ITech IT6502D
- Achieve max. voltage/current within rated power
- Low noise and ripple, comparable with linear power supply
- High resolution of 1mV, 1mA
- Compact, high density, rack-mount size
DC Power Supply 80V / 60A 800W
IT6500 series power supply is single output high-powered and programmable DC power supply that supports CC mode and CV mode. The 1200W model has 1U ultrathin body with 1mV, 1mA resolution the 3000W model outputs adjustable voltage/current value within 80V/120A. In the meanwhile, some models are equipped with DIN40839 and ISO-16750-2 standard waveforms. IT6500 provides you with multiple proposals to meet your test demands.
Power Supplies/DC Power Supplies Template | |
|---|---|
| Outputs | Single |
| Voltage Output 1 | Variable |
| Max Voltage Output 1 | 80 V |
| Programmable | Yes |
| Current Output 1 | Variable |
| Max Current Output 1 | 60 A |
| Meter Type | Digital |
| Switching | Yes |
| Linear/Switching | Switching |
| Max Display Resolution Current | 1 mA |
| Max Display Resolution Voltage | 1 mV |
| Constant current/voltage | Yes |
| Remote Sensing | Yes |
Product General Attributes | |
| Unique Features | Auto-Range function High Resolution Display (1mV/1mA) RS232/USBTMC/RS485 standard interfaces Analog Control Interface Adjustable voltage rising/falling speed Master/Slave Mode for Series/Parallel connectivity Adjustable voltage slope (rise and fall time) OVP/OTP/current limit protection 1U Rackmount kit |
| Warranty | 2 YEARS |
| Safety Approval | CE |
| Interfaces I/O | RS-232, RS-485, USB Interfaces I/O Built-in communication interfaces |
| Product Weight | 18.7 LBS |
| Product Height | 1.7 IN |
| Product Length | 19.7 IN |
| Product Width | 16.3 IN |
| Shipping Weight | 30.8 LBS |
| Data Logging | Yes |
| Calibration Included | Factory Calibration |
| Power Supply Voltage | 120V/220V Universal |
| Country of Origin | China |
| Shipping Height | 8.3 IN |
| UPC | 6970341180997 |
| Shipping Length | 24.4 IN |
| Shipping Width | 22.6 IN |
You must be logged in to post a review.
Manuals/Guides
| Weight | 18.7 lbs |
|---|---|
| Dimensions | 19.7 × 16.3 × 1.7 in |
