ITech IT6932A – DC Power Supply 200W 60V/10A
12 people are viewing this product right now
$660.00
Shipping calculated at checkout.
Estimated delivery:4 days
DC Power Supply 200W 60V/10A
- IT6932A 200W DC Power Supply 60V / 10A
- List Mode: generate, store and execute test
- Sequences without the need for an external computer
- Built-in communication interface: RS232/USB
- Output Timer (0.1 ~ 99999.9S) Function
- Remote Sense Function
- OVP/OCP/OTP protection functions
- Intelligent fan control
- VFD display
- Output on/off control
Guarantee Safe and Secure Payment Checkout
Description
ITech IT6932A
- VFD display
- Output on/off control
- Convenient data entry via knob or numerical keypad
- High accuracy and high resolution: 1mV/0.1mA
DC Power Supply 200W 60V/10A
IT6900A series is a flexible range of single-output power supplies. With an easy-to-read VFD display, High accuracy, and resolution of up to 1mV/0.1mA. It allows the generation and storage of programmed sequences directly from the front panel. Built-in RS232, USB interfaces to provide flexibility for remote operation. IT6900A is a compact, laboratory-grade power supply well-suited for application in the design field, production, or use in university labs.
IT6900A series power supply has adopted Auto-range technology. One unit could replace multiple units with different specifications. Take IT6932A (60V/10A/200W), as an example, the user could use 60V/3.3A/200W instruments and also a 20V/10A/200W unit.
Power Supplies/DC Power Supplies Template | |
|---|---|
| Outputs | Single |
| Voltage Output 1 | Variable |
| Max Voltage Output 1 | 60 V |
| Programmable | Yes |
| Current Output 1 | Variable |
| Max Current Output 1 | 10 A |
| Meter Type | Digital |
| Switching | Yes |
| Linear/Switching | Switching |
| Max Display Resolution Current | 0.1 mA |
| Max Display Resolution Voltage | 1 mV |
| Constant current/voltage | Yes |
| Remote Sensing | Yes |
Product General Attributes | |
| Unique Features | High visibility vacuum fluorescent display (VFD) Convenient data entry via knob or numerical key pad High accuracy and high resolution Low ripple and low noise Intelligent fan control, energy conservation, noise reduction Standard communication interface RS232/USB Output voltage and current values accordance with procedure (LIST mode) Standard SCPI protocol, convenient for secondary-development Timer function (0.1 ~ 99999.9 s) OVP/OCP/OTP protection |
| Warranty | 2 YEARS |
| Safety Approval | CE |
| Interfaces I/O | RS-232, USB Interfaces I/O Built-in communication interfaces |
| Product Weight | 16.9 LBS |
| Product Height | 3.5 IN |
| Product Length | 14 IN |
| Product Width | 8.4 IN |
| Shipping Weight | 22.7 LBS |
| Data Logging | Yes |
| Calibration Included | Factory Calibration |
| Power Supply Voltage | 120V/220V Universal |
| Country of Origin | China |
| Shipping Height | 11.8 IN |
| UPC | 6970341180942 |
| Shipping Length | 20.1 IN |
| Shipping Width | 16.1 IN |
You must be logged in to post a review.
Manuals/Guides
| Weight | 16.9 lbs |
|---|---|
| Dimensions | 14 × 8.4 × 3.5 in |
