Description
Kanomax 3950
- Portable particle counter for high-end contamination control environments
- 0.1 μm sensitivity
- 2-channels (0.1-0.3 μm)
- 4.3-inch color touchscreen display
- Interface: RS-485, Ethernet, USB
Portable Particle Counter, 0.1 – 0.3 Micron, 2-Channel
The Kanomax 3950 is a 0.1-0.3 micron 2-channel semiconductor particle counter that comes in one of the lightest form factors available today, weighing in at only 7.5 lbs (3.4kg). The 3950 is designed for high-end contamination control environments, such as semiconductor manufacturing facilities and cleanrooms, and can be used for standalone operation or integrated into an existing monitoring system to accommodate a vast array of applications.
Device operation is made easy with its built-in 4.3-inch LCD color touchscreen, ability to store up to 10,000 records, and USB data transfer capability. The included PC software allows the monitoring of environments in real time.
Components and Functions
1. Inlet – Suction volume: 2.83 L/min, O.D.: 6.4mm
2. DC power terminal – Connects to the main unit with the AC adapter
3. Communication terminal – RS-485 communication
4. USB terminal (for PC) – Connects to PC with a USB cable
5. USB terminal – Connect to printer / USB memory
6. Communication terminal – Ethernet communication
7. Power switch – Switch the main unit on/off
Indoor Air Quality/Particle Counter Template | |
|---|---|
| Style (IAQ) | Portable |
Product General Attributes | |
| Interfaces I/O | LAN / Ethernet, RS-485, USB |
| Product Weight | 7.49 LBS |
| Product Height | 6.41 IN |
| Product Length | 8.97 IN |
| Product Width | 5.90 IN |
