Keysight U1253B – True RMS 50K Count Handheld DMM with OLED Display

• 50K count DMM with an OLED display; Keysight Meter Logger capable; Built-in battery charging
• Resistance, frequency, capacitance, continuity, diode, temperature, frequency counter, square-wave
• Min/Max recording, display hold, peak hold, null, PC-connectivity, manual data logging
• Overvoltage protection rating: CAT III 1000V and CAT IV 600V
• Store up to 2,000 readings in multimeter, IR-to-USB or Optional Bluetooth to transfer data to the PC

The Keysight U1250 Series handheld digital multimeters (DMMs) exceed your expectations by delivering powerful features and performance that meet your toughest requirements and applications.

The basic model, U1251B, expands capabilities beyond typical DMM measurements to include data logging. The U1252B starts with the same foundation and then adds a 20-MHz frequency counter and programmable square-wave generator— perform more tests conveniently with one tool.

Offering the same functionality as the U1252B, the U1253B is the world’s first OLED handheld DMM. You won’t have to squint to be sure you’re reading it right: On the go or on the bench, get crystal-clear viewing indoors, even in dark, off-angle situations.

Find Problems Quickly

Troubleshooting can be tricky, especially when you’re dealing with elusive problems. With the U1250 Series’ data logging capability, the user can be sure that every reading gets recorded manually or at specified intervals. Virtually unlimited data logging saves when connecting any of the U1250 Series DMM to a PC with the optional IR-to-USB cable. In addition, the U1250 Series lets you achieve greater confidence in your measurements with accurate true-RMS AC measurements, a low DCV error rate of up to 0.025% and a high-resolution display of 50,000 counts.

Rugged and Safe

The U1250 Series DMMs are housed in robust over-molded enclosures, rated at CAT III 1000 V and CAT IV 600 V, and operate over a wide temperature range of –20 °C to +55 °C. Each DMM also includes a 30 kA high-energy fuse to further protect you against violent fuse failures during high-current measurements. Built tough and certified to stringent industrial standards, the U1250 DMM is what you need to face the demands of everyday tasks.
