Mark-10 M2-50 – Series 2 Economical Digital Force Gauge (50lbF / 25kgF / 250N)
29 people are viewing this product right now
Original price was: $2,450.00.$2,327.50Current price is: $2,327.50.
Shipping calculated at checkout.
Estimated delivery:5 days
Force gauge, 50 lbF / 25 kgF / 250 N-Note:Price is for 5 Units
- Series 2 Force Gauge calculates peak tension, compression values – 50lbF / 25kgF / 250N
- USB data output of continuous or individual data points
- 500 Hz sampling rate; Accuracy +/-0.5% of full scale
- 3 selectable units of measurement
- Ultra-compact, ergonomic housing
- Configurable default measurement unit and mode
- Large, backlit graphic display with auto-dimming
- Powered by rechargeable battery or AC adapter
- Reversible housing for alternate load cell orientation
- Cushioned carrying case for storing the AC adapter, USB cable
Guarantee Safe and Secure Payment Checkout
Description
Mark-10 M2-50
- Series 2 Force Gauge calculates peak tension, compression values – 50lbF / 25kgF / 250N
- USB data output of continuous or individual data points
- 500 Hz sampling rate; Accuracy +/-0.5% of full scale
- 3 selectable units of measurement
- Cushioned carrying case for storing the AC adapter, USB cable
Series 2 Economical Digital Force Gauge (50lbF / 25kgF / 250N)
Mark-10 Series 2 digital force gauges are designed for basic tension and compression force testing applications up to 500lbF (2,500N). Peak tension and compression readings are reliably captured via the gauges’ +/-0.5% accuracy and 500Hz sampling rate. A backlit graphic LCD displays the current, peak tension, or peak compression reading. USB output is provided for data collection purposes.
The gauges are overload protected to 200% of capacity. An ergonomic, reversible aluminum housing allows for handheld use or fixture mounting, rugged enough for applications in both production and laboratory environments. Series 2 gauges are directly compatible with Mark-10 test stands and grips (please see accessories for options).
Mark-10 Series 2 Ordering Info and Dimensions
Force / Torque / Hardness Meters/Force Meter Template | |
|---|---|
| Capacity | 50 LBS |
| Resolution (Force) | 0.05 LBS |
| Accuracy | ±0.5% of full scale |
| Sampling Rate (Force) | 500 Hz |
| Compression Option | Yes |
| Programmable | Yes |
| Memory Capability | No |
| Process Output | Yes |
| Tare and Hold | No |
| Set Points | No |
Product General Attributes | |
| Interfaces I/O | USB |
| HTS/Schedule B Number | 9024.10.0000 |
| ECCN Number | EAR99 |
| Country of Origin | United States |
