Mountz 068405 – 3/8″ LTT50F Torque Analyzer

• Wrenches or power tools
• Features ARCII technology
• Stores a total of 5000 data points
• Recommended for all hand screwdrivers
• Provides EZ-Plug & Play w/Mountz torque sensors

The Mountz 068405 is a torque analyzer is designed for calibrating tools, joint testing, auditing, and measuring torque. Torque tools go out of calibration with use. To maintain consistent accuracy, torque tools must be checked periodically for wear or defective parts. A power or hand torque tool is a measuring tool that must be properly calibrated and maintained. The LTT-Series is an advanced torque testing and documentation solution. Using a quality torque tester makes a safer world through accuracy and precision. Controlling torque is essential for companies to ensure their product’s quality, safety, and reliability aren’t compromised.

• Selection of six operation modes: (Track, Peak, First Peak, Audit, Spindle Audit and Torque + Angle)
• Seven units of torque measurements: (ozf.in, lbf.in, lbf.ft, cN.m, N.m, kgf.m, kgf.cm). Two units of force measurements: (lbf and kN)
• Features built-in tool tests operation
• Real-time graph of torque vs. time using associated PC Windows software
• Features Go / No Go LEDs that illuminate when high or low setting is achieved
• Run Down Adapter (RDA-50F) is included with LTT50F Use the RDA when testing and calibrating the power tool.
• Easy-to-use menu structure, a six-digit display and connect to an external torque sensor
• High capacity Li-Ion batteries for long life (30 hrs with standard torque sensors and 16 hrs with brushless rotary sensors)
• Can connect to most mv/v torque sensors and can store calibration data for up to 50 non-smart torque & force sensors
• The 5VDC capability allows the unit to be used with a Brushless Rotary torque sensor for testing pulse tools and high RPM tools
• Torque and Angle data is displayed simultaneously when used with Torque and Angle sensors, up to 8000 RPM for angle measurement
• Display Accuracy is better than +/- 0.0625 of reading
• Five low-pass filter selections (3000, 2000, 1500, 500 and 200 Hz)
• Flash,  memory allows upgrades to be done by the user in the field & internet through the USB port

NOTE: Run Down Adapter (RDA-50F) is included with LTT50F. Use the RDA when testing and calibrating the power tool.
