PCE Instruments PCE-PQC 15US – Particle Counter with NIST Calibration (0.5 – 75 um)

• Measuring range: 0.5 – 75 μm
• Measuring channel sizes: Factory calibrated at 0.5, 1.0, 2.5, 5.0, 10.0, 30.0 μm
• Counting efficiency: 50% at 0.5 μm 100% at > 0.75 μm according to JIS
• 6 measuring channels, the upper 2 channels can be adjusted
• Handheld, portable, lightweight with kickstand

The particle counters of the PCE-PQC 1xUS series measure the concentration of particles such as dust, soot, pollens, and many other aerosols in the air. These particle counters were developed to accurately determine the degree of pollution in the air. Pollution is mainly generated by combustion, material processing, manufacturing, power generation, vehicle engine emissions, and the construction industry and may be invisible to the eye.

The PCE-PQC 1xUS series particle counters allow the user to measure the exact amount of dirt particles in the air. Secondarily important is the degree of air pollution with pathogenic particles such as soot, which are released by heavy industry and especially by diesel vehicles without special filtering of the air. These dispersion particles are responsible for many respiratory issues, shortness of breath, bronchitis, asthma, stroke, and heart attack, and thus reduced labor productivity. The particle counters of the PCE-PQC 1xUS series operate in different modes (real-time, cumulative, differential, and mass concentration) and display the results on display with the ability to graph trends and save data remotely.
