PCE PCE-172 – Lux Meter

• 3½ position LCD; maximum reading is 1999
• Ranges: 40.0 / 400.0 / 4000 / lux ; 40.00 / 400.0 klux ; 40.00 / 400.0 / 4000 / fc ; 40.00 kfc
• Resolution: 0.01 / 0.1 / 1 / 10 / 100 lux ; 0.01 / 0.1 / 1 / 10 Foot-candle
• Measurement units can be displayed in lux or foot-candles
• Backlit display

The Illuminometer PCE-172 is used to measure the lighting conditions in industry, agriculture and research. Increasingly, the illuminometer  is also used to test lighting in workplaces, in the decoration of shop windows and by designers. It meets international standards for this type of illuminometer.

The illuminometer provides measurement results in Lux and Foot-candle units, where 1 fc is equal to 10.70 lux. Calculator for the conversion of lux. The device automatically detects the peak value if this value lasts for at least 10 μs. Due to the selectable measuring range the illuminometer PCE-172 has high accuracy. The handling is very easy. This illuminometer can also be used by untrained persons. However, it is always important to take into account in a lux measurement that certain conditions are met. For example, the distance and angle between the illuminometer and the object to be measured should be set as accurately as possible in order to achieve reproducible results.
