Rigol DS1054Z Kit2 Digital Oscilloscope with Extra 50 ohm impedance adapter

Rigol DS1054Z Kit2 – Digital Oscilloscope with Extra 50 Ohm Impedance Adapter

Best Selling Oscilloscope

Find out why the DS1054Z is one of the top selling oscilloscopes in the WORLD since its release in September 2014. Read the reviews! Let our customers tell you what they think of this unit. Schools, companies, students and home hobbyists love the DS1054Z. Backed by a 30 day money back guarantee you cannot go wrong with this unit.

Why do I need the Adapter?

When working with RF, many circuits are designed to operate with transmission lines with a 50 Ohm characteristic impedance or a filter with an input / output impedance of 50 ohms. The input impedance of an oscilloscope is typically 1 megohm at the connector. This impedance mismatch can cause a large numbers of anomalies and artifacts on the measured signal that wouldn’t normally be there along with causing inaccurate amplitude measurements. Providing a 50 Ohm input impedance at a oscilloscope input allows measurements without disturbing the impedance matching of the circuit under test. For example, passive filters that are designed for 50 Ohm source and load impedance will display drastically different characteristics when terminated with anything other than 50 Ohms.

UltraVision

Rigol’s innovative UltraVision technology provides a deeper memory depth of 12Mpts standard and is upgradeable to 24 Mpts (with purchase of MEM-DS1000Z). The DS1054z also provides the ability to quickly focus in on certain piece of a recorded waveform.

Full Visibility

The large 7″ display of the DS1054z, with a resolution of 800 X 480 pixels makes it possible to view all channels on a single screen. This makes for better usability and more efficient analysis.

Ultra-fast Sampling Rate

Rigol has given the DS1000z series the ability to capture up to 30,000 waveform per second. This coupled with the 12 Mpts of memory and sampling rate of 1 GS/s makes this a great oscilloscope for nearly any application.

Optional Waveform Recording

Rigol has made recording waveforms an accessible option for all users with the simple purchase of the DS1000Z-REC software option. This allows users to go back and analyze previous data.

Multi-Level Intensity Graded Display

This feature provides users the ability to focus in and visually detect event frequency over time.

Advanced Triggering Options

Adding to the flexibility of the DS1000Z line up, Rigol has added the option to purchase and advance triggering feature. This includes triggering options such RS232/URAT, I2C, SPI, Runt, Windows, Nth Edge, Delay, Time Out. This option can be purchased under product number AT-DS1000Z.

Serial Bus Analysis Options

By purchasing the SA-DS1000Z Serial Bus Analysis Option, users can examine, decode and view RS232/URAT, I2C, SPI.

Advanced Signal Calculations

Rigol has integrated an advanced system of formulas designed to resolve complex signal calculations.
