Siglent SNA5032A – Vector Network Analyzer (2 Ports; 100 kHz – 26.5 GHz)
30 people are viewing this product right now
$40,106.00
Shipping calculated at checkout.
Estimated delivery:5 days
Frequency Range: 100 kHz~26.5 GHz, 2 ports Frequency Resolution 1 Hz, IFBW 10 Hz~3 MHz, Dynamic Range 125 dB, Output Level Range -55 dBm ~ +10 dBm, 12.1 inch Touch Screen
- 2 ports
- Frequency range: 100 kHz – 26.5 GHz
- Supports scattering, differential, time domain parameter measurements and more
- Effective for determining Q factor, bandwidth and insertion loss of a filter
- Five sweep types: linear frequency, log frequency, power sweep, CW-time and segment sweep
- Types of calibration: Response, enhanced response, TRL and more
- Supports bias tees
- Interface: LAN, USB Device, USB Host(USB-GPIB)
- Remote control: SCPI/Labview/IVI based on USB-TMC/VXI-11/Socket/Telnet/WebServer
- 12.1-inch touch screen
Guarantee Safe and Secure Payment Checkout
Description
Siglent SNA5032A
- 2 ports
- Frequency range: 100 kHz – 13.5 GHz
- Supports scattering, differential, time domain parameter measurements, and more
- Effective for determining Q factor, bandwidth, and insertion loss of a filter
- Five sweep types: linear frequency, log frequency, power sweep, CW-time, and segment sweep
Vector Network Analyzer (2 Ports; 100 kHz – 26.5 GHz)
The SIGLENT SNA5000A series of Vector Network Analyzers have a frequency range up to 26.5 GHz, and support 2/4-port scattering-parameter, differential-parameter, and time-domain parameter measurements.
The SNA5000A series of VNAs are effective instrumentation for determining the Q-factor, bandwidth and insertion loss of a filter. They feature impedance conversion, movement of measurement plane, limit testing, ripple test, fixture simulation and adapter removal/insertion adjustments. The SNA5000A have five sweep types: Linear-Frequency mode, Log-Frequency mode, Power-Sweep mode, CW-Time mode and Segment-Sweep mode. These also support scattering-parameter correction of SOLT, SOLR, TRL, Response and Enhanced Response for increased flexibility in R&D and manufacturing applications.
Several versions available
The SNA5000A is available with either two or four ports, and a maximum bandwidth of up to 26.5 GHz. The chart below provides an overview of available models:
| SNA5002A | SNA5004A | SNA5012A | SNA5014A | SNA5022A | SNA5032A | |
| Frequency | 9kHz-4.5GHz | 9kHz-4.5GHz | 9kHz-8.5GHz | 9kHz-8.5GHz | 100kHz-13.5GHz | 100kHz-26.5GHz |
| Ports | 2 | 4 | 2 | 4 | 2 | 2 |
Design Features
Multi-window display
Multi-format display
Display and compare memory and current data
Display data hold
Port Extensions
Time-Domain analysis
Spectrum Analyzers/Spectrum Analyzers Template | |
|---|---|
| Bandwidth Range Max | 26.5 GHz |
| Bandwidth Range Min | 100 kHz |
| Type(Spectrum Analyzers) | Benchtop |
Product General Attributes | |
| Interfaces I/O | LAN / Ethernet, USB Host, USB |
