SPM Vibration SLD122B-M8 – Vibration Transducer (VIB Transducer 2-5000Hz, 2-pin, M8)

• Frequency: 2 – 5000 Hz
• 2-pin connection
• M8 mounting thread
• Sensitivity: 1.2 mV/m/s2
• Individually tuned piezo-electric accelerometer of compression type

Vibration transducers

The transducers are piezo-electric accelerometers of compression type; each individually tuned, with a built-in pre¬amplifier, designed for vibration monitoring of industrial machinery. The electrical signal is isolated from the transducer housing. Enhanced electronics and improved ambient characteristics deliver excellent performance in a very large area of applications.

The transducers are designed to withstand the rigors of industrial environments. Stainless, acid-proof steel housings, case isolation, and hermetic sealing make them very robust.

Technical overview

SPM vibration transducers come in a variety of sizes, configurations, and specifications to perfectly suit your needs. All transducers are internally isolated. The frequency range is specified for the transducer when permanently installed. The measuring results will be affected at higher frequencies when using a magnetic foot.
