Tektronix CT1 – AC Current Probes (200 μA, 1 GHz, < 350 ps)
29 people are viewing this product right now
Original price was: $1,240.00.$1,178.00Current price is: $1,178.00.
Shipping calculated at checkout.
Estimated delivery:5 days
CURRENT XMFR; 1GHZ 12A W/PROBE – STATEMENT OF COMPLIANCE
- Maximum Current:
- Peak: 12 A
- Max RMS: 450 mA continuous
- Minimum Current: 200 μA
- Bandwidth: 1 GHz
- Rise Time: < 350 ps
- High Bandwidth
- Ultra-low Inductance
- Very Small Form Factor
- Very Low Loading of Circuit Under Test
- Fits Into Dense, Closely-spaced Circuit Designs
Guarantee Safe and Secure Payment Checkout
Description
Tektronix CT1 – AC Current Probes (200 μA, 1 GHz, < 350 ps)
- Maximum Current:
- Peak: 12 A
- Max RMS: 450 mA continuous
- Minimum Current: 200 μA
- Bandwidth: 1 GHz
- Rise Time: < 350 ps
The CT1 Current Probes are designed for permanent or semi-permanent in-circuit installation. Each probe consists of a current transformer and an interconnecting cable. The current transformers have a small hole through which a current carrying conductor is passed during circuit assembly.
The P6041 Probe Cable provides the connection between the CT1 and CT2 Current Transformers and a BNC oscilloscope input. A 50 Ω termination is required to terminate the cable when connected to a high-impedance (1 MΩ) oscilloscope input. One probe cable can be used to monitor several current transformers that have been wired into a circuit.
Product General Attributes | |
|---|---|
| Product Height | 0.80 IN |
| Product Length | 11.40 IN |
| Product Width | 8.75 IN |
| Country of Origin | China |
| Shipping Height | 0.80 IN |
| Shipping Length | 11.40 IN |
| Shipping Width | 8.75 IN |
You must be logged in to post a review.
Manuals/Guides
Spec SheetsApplication Notes
| Dimensions | 11.4 × 8.75 × 0.8 in |
|---|
