Description
Televes 238081 – FiberKom RFoG Mininode with Return TX (1310nm / 3dBm) – 2 Fibers
Complete range of headend devices to convert CATV and L-Band signals into light for distribution on PON networks. Convert the light to RF at the other end to put it back on a coaxial distribution network (FTTx) with a complete range of receivers and mini-nodes too.
Operating mode upstream:
There are two modes available for upstream operation:
- RFoG mode: The laser is switched ON only when a upstream signal is present.
- CW mode: The laser is permanently ON.
Forward path: The output level of the mini-node is kept constant by OLC. The RF output level can be adjusted using the inter stage attenuator.
Input and Output Description
- Power
- Optical Output (3 dBm)
- Laser switch ON indicator 4
- Optical Input (2 dBm max.)
- Optical level indicator (OLC)
- (red) > +1 dBm
- (green) -8 … +1 dBm
- (orange) < -8 dBm
- Test RF (-30dB)
- RF IN/OUT
Video Distribution Equipment/Fiber Optic Transmitters / Receivers / Nodes | |
|---|---|
| Type (Fiber Optic Tx Rx Node) | Fiber Optic Nodes |
Product General Attributes | |
| Country of Origin | Spain |
