273-10-120VAC CURRENT MONITOR
- Current range: 0.5 to 5 amps or 2 to 10 amps
- Supply voltage: 24VAC or 120VAC
- 8-pin socket
- Adjustable trip point
- Over or under current sensing
- 5 or 10 amp adjust range options
- Five-year unconditional warranty
Guarantee Safe and Secure Payment Checkout
Description
Time Mark 273-10-120 – Single Phase Current Monitor
- Current range: 0.5 to 5 amps or 2 to 10 amps
- Supply voltage: 24VAC or 120VAC
- 8-pin socket
- Adjustable trip point
- Over or under current sensing
- 5 or 10 amp adjust range options
The Time Mark 273-10-120 Single Phase Current Monitor is a single set-point sensor. It can be used as either an over current or under current sensor, depending on the contacts used.
This device can directly monitor AC currents in the range of 0.5 to 5 amps: or 2 to 10 amps, 50 to 400 Hz. Matching transformers are available to extend the use of the monitor to most any range. The current being monitored can be of any voltage, up to the rating of the socket. An LED indicator is provided to show when the relay is energized. The Model 273 is available for either 24 VAC or 120 VAC supply voltages.
Current Monitor Relays | |
|---|---|
| Max Current AC | 10 A |
| Nominal Voltage (monitor relays) | 24/120 VAC |
| Time Mark Mounting | 8-pin |
Product General Attributes | |
| Warranty | 5 YEARS |
| Warranty Details | Time Mark Corporation offers a 5-year unconditional warranty on all of our 3-Phase Monitors and socket mounted products. All other standard products have a 1-year warranty. |
| Product Weight | 0.4 LBS |
| Product Height | 1.95 IN |
| Product Length | 1.95 IN |
| Product Width | 3.25 IN |
| Country of Origin | United States |
| Shipping Height | 3.25 IN |
| UPC | 662917003729 |
| Shipping Length | 1.95 IN |
| Shipping Width | 1.95 IN |
You must be logged in to post a review.
Manuals/Guides
Spec Sheets
| Weight | 0.4 lbs |
|---|---|
| Dimensions | 1.95 × 3.25 × 1.95 in |
