Description
Tinker & Rasor T-3 – Test Station with Hardware, 11 Holes with 5 Binding Posts (Indicate Color When Ordering)
- Picture is for illustrative purposes – this product is one test station
- Please indicate color choice when ordering
- Eight color choices available: black, purple, red, orange, white, green, yellow, blue
- 11 hole terminal board
- Fits 3.5″ OD riser pipe
The Tinker & Rasor T-3 is a cathodic protection test station with five binding posts and an eleven hole terminal board.
Please note, the T-3 is available in eight colors. Please indicate your color choice when ordering. The color options are:
- Black
- Purple
- Red
- Orange
- White
- Green
- Yellow
- Blue
T-3 cathodic protection test stations come standard with the unique Tinker & Rasor binding post and set screw.This binding post allows for rapid wire connections on wires as big as 6 AWG.Each T-3 comes with five nickel plated binding posts.
The T-3 also features a clear terminal board made of tough, fire resistant polycarbonate resin.The clear terminal allows you to view both sides of the terminal board without obstruction.
The terminal board has 11 terminal positions, most on 1″ centers from another.
The T-3 is injection molded using Lexan polycarbonate plastics to ensure maximum strength and UV protection to guard against failure due to prolonged exposure to sunlight. It is designed to survive in harsh climates worldwide and comes with a limited 25-year warranty.
These unique test stations are designed for easy installation on either new or existing risers and require no tools. Other features include the exclusive “Supergrip Top”, making it easy to open the Test Station while wearing gloves, and the “Anti-spin” gasket, which prevents the possibility of the test stations “spinning” on the riser.
Fits 3.5″ OD riser pipe, also available from stock in three colors. Reducing adapters available for smaller O.D.’s and a flange adapter, as well. Large, clear terminal board can handle a variety of custom configurations, including voltmeters, shunts, resistors, potentiometers and more.
Product General Attributes | |
---|---|
Warranty | 90 DAYS (0.247 YEARS) |
Warranty Details | Parts and labor |
Product Height | 6.00 IN |
Product Length | 6.00 IN |
Product Width | 4.00 IN |
Shipping Weight | 1 LBS |
Shipping Height | 6 IN |
Shipping Length | 6 IN |
Shipping Width | 4 IN |
