Triplett EMF85 – Triple Axis EMF Meter (50MHz to 8GHz)

• Designed for wide-band monitoring of high frequency radiation from 50MHz to 8GHz
• Applications: Cell phone base station antennas, wireless comms (CW,TDMA,GSM,DECT), Wi-Fi networks
• Non-directional (Isotropic) measurement with built-in 3-axis (XYZ) probe
• Measurement Range: 1µW/m2 to 26.52W/m2; 0µW/cm2 to 2.652mW/cm2; 20mV/m to 100V/m
• Displays Actual, Average, Max and Max Average measurements

The Triplett Model EMF85 Triple Axis EMF Meter is designed for wide-band monitoring of high frequency radiation from 50MHz to 8GHz including the measurement of electromagnetic radiation intensity of cellular phone base station antennas, wireless communication applications (CW, TDMA, GSM, DECT), RF high frequency transmitter power measurement, Wi-Fi network detection and Installation, detection of radiation leakage from microwave ovens, evaluation of electromagnetic wave safety in company or home environments, and other applications.

The Triplett EMF85 EMF Meter features non-directional measurement using a built-in 3-axis (XYZ) probe with readout in 3 units of measure: µW/m2, mW/m2, W/m2, µW/cm2, mW/cm2, mV/m , V/m. It displays actual, average, max and max average measurements on the easy-to-read color LCD display with 4 brightness levels and has a programmable audible high limit alarm. Manually store up to 10,000 points and recall them on the display using the historical data function arranged in order of record and time or transfer the recorded data to a PC in csv format using the built-in USB interface. Includes rechargeable 3.7V Li-ion battery, USB cable, and soft carrying case.

• Measurement of electromagnetic radiation intensity of cellular phone base station antennas
• Wireless communication applications (CW, TDMA, GSM, DECT)
• Safe use of RF high-frequency electromagnetic waves
• RF High Frequency Transmitter Power Measurement
• Wireless Network (Wi-Fi) Detection, Installation
• Wireless pinhole camera and eavesdropper detection
• Electromagnetic Radiation Intensity Measurement for Home Radio Telephone
• Detection of radiation leakage from microwave ovens
• Evaluation of electromagnetic wave safety in company or home environment
