Triplett PCAL200 – Voltage and Current Source Calibrator

Brand:
23 people are viewing this product right now

Original price was: $399.99.Current price is: $287.41.

Shipping calculated at checkout.
or
Add to quote
Estimated delivery:3 days

Voltage and Current Source Calibrator

  • Precision calibrator provides 0.05% accuracy for voltage and current source outputs
  • Versatile tool for various applications in electronics testing, calibration, research, and development
  • Versatile current span adjustment (0-20mA/4-20mA) with percentage readout
  • Choose between automatic sawtooth or triangular output current step functions
  • Built-in functions include flashlight, auto power off, low battery indicator
  • DC Voltage Range (Resolution): 10V (0.001V)
  • DC Current Range (Resolution): 30mA (0.001mA)
  • Maximum Load: 1000Ω at 10mA
SKU: Triplett PCAL200 EAN: 614395005443 Tags: , Categories:
Pay safely with Visa Pay safely with Master Card Pay safely with PayPal Pay safely with Maestro Tooltip text
Guarantee Safe and Secure Payment Checkout

Description

Triplett PCAL200

  • Precision calibrator provides 0.05% accuracy for voltage and current source outputs

  • Versatile tool for various applications in electronics testing, calibration, research, and development
  • Versatile current span adjustment (0-20mA/4-20mA) with percentage readout
  • Choose between automatic sawtooth or triangular output current step functions
  • Built-in functions include flashlight, auto power off, low battery indicator

Voltage and Current Source Calibrator

The Triplett PCAL200 DC Voltage and Current Source provides an adjustable 0-20mA/4-20mA span with % readout and a 0 to 10V DC voltage range with 0.05% accuracy that can be used for benchtop and field industrial process device testing and calibration. It features automatic sawtooth or triangular output current step function, on-screen low battery indication, auto power off, and a built-in flashlight. The Triplett PCAL200 includes test leads, (3) AA batteries, (2) spare fuses, and latch key (for opening battery door).

​

Triplett PCAL200 – Voltage and Current Source Calibrator Applications

The PCAL200 TDC Voltage and Current Source is a versatile tool suitable for various applications in fields such as electronics testing, calibration, research, and development.

  • Calibration Labs
  • Process Control
  • Electronic Circuit Testing
  • Instrumentation Development
  • Sensor Testing and Validation
  • Automated Test Systems
  • Educational Laboratories
  • Research and Development
  • Battery Testing
  • LED and Lighting Testing

Process / Calibration/Signal Calibrators/Voltage Calibrators Template

Style (Voltage Calibrators)Hand Held
Display (Voltage Calibrators)Single
Measure Input VoltageNo
Source Ouput VoltageYes
Maximum Source Voltage10 V
Voltage Accuracy±(0.05% + 2mV)
Current MeasurementNo
Current Source OutputYes
Measure T/CNo
Measure RTDNo
Measure ResistanceNo
Measure FrequencyNo
Measure VoltageNo
Measure CurrentNo
Auto Step/RampNo

Process / Calibration/Milliamp Calibrators Template

Source/Simulate DC CurrentYes
Measure DC CurrentNo
Two Wire Transmitter SimulationNo
Percent DisplayYes
Accuracy±(0.05% + 4µA)
Simulate Loop VoltageNo
BacklightYes
Ramp/Step OutputYes
FieldBus CompatibleNo
