UNI-T UT8803E – 3.8 Digit Classic-Series True RMS Benchtop Digital Multimeter

• Measures resistance, capacitance, frequency, capacitance, inductance, diodes, SCR, hFE, continuity
• AC voltage range (True RMS): 600mV – 750V
• DC voltage range: 600mV – 1000V
• AC current range (True RMS): 600uA – 10A
• DC current range: 600uA – 10A

The UNI-T UT8803E is an auto/manual range, AC powered, True RMS, benchtop digital multimeter that features 6000 display counts, a large backlit LCD, and full scale overload protection. The UT8803E is a comprehensive universal test instruments that measures AC/DC Voltage and Current, resistance, frequency, capacitance, inductance, temperature, triode, hFE, diode (LED), SCR, continuity, and other items, meeting user needs with multi-function, high precision and automation.

The UNI-T UT8803E digital multimeter can display 3.8 digits (6000) to provide a high precision and accurate results. The UNI-T UT8802E includes a diode test function that allows you to determine the on-voltage and diode polarity. The multimeter has a maximum and minimum value statistics function to aid in identifying peak and trough values during batch testing or multiple measurements. The multimeter also allows measurement of D/Q parameters for capacitance and inductance. (Press the DQR key during capacitance and inductance measurements to view these parameters). The UT8803E has a ‘REL’ button, that can set a reference value for measurements, allowing calculation of results relative to the reference value. Connect the Uni-T UT8803E to a PC (via USB port) and install the driver software (included) for the ultimate convenience. You’ll gain access to remote viewing, allowing you to monitor historical data and trend charts in real-time. The UT8803E can measure triode/thyristor with the adapter UT-S03A (included).
