UNI-T UTS1015B – Benchtop Spectrum Analyzer (9kHz – 1.5GHz)

• Frequency measurement range: 9kHz – 1.5GHz
• This version does not include a tracking generator
• 10.1” multi-touch HD screen with gesture support
• Display average noise level can be as low as -161 dBm (typical value)
• 4 traces are provided to facilitate comparative observation and find abnormal signals

The UNI-T UTS1000B/T series are swept spectrum analyzers with a frequency range from 9kHz to 3.2GHz (model dependent) and are suitable for use in many different applications.

The chart below outlines several main features of each.

Weak signals are easily affected by the noise floor of the spectrum analyzer itself. The UTS1000B/T series features a displayed average noise level (DANL) as low as -161dBm, which is very useful when working with weak test signals.

The UTS1000B/T provides four traces to facilitate comparative observation and find abnormal signals.

The UTS1000B/T features a 10.1” multi-touch screen which supports multiple gesture functions including dragging, expanding, and zooming.

When used with optional near-field probes (part number UTS-EMI01), software option UTS1000B-EMI can help you find and improve EMI defects in advance, shortening the development cycle.

The advanced measurement kit provides several additional measurement functions for the UTS1000B/T. Functions include channel power, adjacent channel power, occupied bandwidth, carrier noise ratio, harmonic measurement, and more.
