Yamato DX-612C – Economical Natural Convection Oven, 153L, 220V
41 people are viewing this product right now
$3,058.00
Shipping calculated at checkout.
Estimated delivery:5 days
Natural Convection Oven, 153L, 220V. (Does not include plug.)
- Internal capacity: 153L
- Power Source: 220V 6.4A (no plug, round terminal)
- Digital PID controller for easy operation with options for Fixed setting, Auto Start, Quick Auto Stop and Auto Stop
- Increased safety and self-diagnostic functions
- Calibration off-set function
- Economical and cost saving
- Easy to use and maintain
- Excellent temperature accuracy
Guarantee Safe and Secure Payment Checkout
Description
![]()
![]()
![]()
![]()
Yamato DX-612C
- Internal capacity: 153L
- Power Source: 220V 6.4A (no plug, round terminal)
- Digital PID controller for easy operation with options for Fixed setting, Auto Start, Quick Auto Stop and Auto Stop
- Increased safety and self-diagnostic functions
- Calibration off-set function
Economical Natural Convection Oven, 153L, 220V
Standard type natural convection constant temperature drying ovens with extensive features and simple operation
Performance and functions
- Economical and cost saving
- Easy to use and maintain
- Excellent temperature accuracy
- Digital PID controller for easy operation with options for Fixed setting, Auto Start, Quick Auto Stop and Auto Stop
- Increased safety and self-diagnostic functions
- Calibration off-set function
Safety features
- Temp sensor error, Temp input circuit error, Auto overheat prevention, Measured temp error, Circuit breaker with over current protection
Control Panel
Method
DX Series Comparison
| SKU | |||
| Max. Temperature Reaching Time | 45 min (Room temp. to 300°C) | 60 min (Room temp. to 300°C) | 80 min (Room temp. to 280°C) |
| Heater | Iron-chrome wire heater 0.9 kW | Iron-chrome wire heater 1.36 kW | Iron-chrome wire heater 1.36 kW |
| Int. Dim. (W×D×H) | 300x310x300mm | 450x410x400mm | 600x510x500mm |
| Ext. Dim. (W×D×H) | 400x440x630mm | 550x540x730mm | 700x640x830mm |
| Internal Capacity | 28L | 74L | 153L |
| Shelf Plate With Standard Load | 15kg/piece | 15kg/piece | 15kg/piece |
| Shelf Rest Step Number / Pitch | 6 steps / 35mm | 9 steps / 35mm | 12 steps / 35mm |
| Power Source 50/60Hz | AC115V 9.5A (with plug) | AC115V 14A (with plug) | AC115V 14A (with plug) |
| AC220V 4.3A (no plug, round terminal) | AC220V 6.4A (no plug, round terminal) | AC220V 6.4A (no plug, round terminal) | |
| Weight | ~23kg | ~38kg | ~56kg |
Incubators | |
|---|---|
| Controls (Life Science) | Digital |
| Capacity (Incubator/Oven/Chamber) | 153 L |
| Voltage (Life Science) | 208-240 VAC Only |
| Max Temp (Incubator/Oven/Chamber) | 280 C |
| Min Temp (Incubator/Oven/Chamber) | 25 C |
| Special Chamber Functions (incl or optional) | Timer |
Product General Attributes | |
| Warranty | 1 YEARS |
| Product Weight | 123.46 LBS |
| Product Height | 32.68 IN |
| Product Length | 25.2 IN |
| Product Width | 27.56 IN |
| Shipping Weight | 142 LBS |
| Shipping Height | 37.58 IN |
| Shipping Length | 29 IN |
| Shipping Width | 31.7 IN |
You must be logged in to post a review.
Manuals/Guides
BrochuresManualsSpec SheetsComparison
| Weight | 123.46 lbs |
|---|---|
| Dimensions | 25.2 × 27.56 × 32.68 in |
