Description

Yamato SM-520
- Internal capacity: 50L
- Power source: 100-120V (no plug, round terminal)
- Interactive keypad input (touch panel) allows committing sterilization settings (time & temperature) to memory
- 7″ interactive touch screen
- Suitable for protein modification at the maximum operating temperature of 135°C
Large Capacity Laboratory Use Sterilizer w/Dryer, 50L, 100-120V
Ultra-high in capacity & performance, Yamato’s large capacity SM steam sterilizer with dryer is designed to take your sterilization to the next level. The Yamato large-capacity autoclaves carry out fully automatic sterilization from start to finish with high-pressure steam sterilization and drying steps. Moreover, the SM sterilizer’s large capacity models can help you efficiently sterilize more samples in a single load, saving you both time and effort. Our large capacity autoclaves come in 50L & 80L capacity options each with a maximum operating temp of up to 135°C.
The large-capacity SM steam sterilizers from Yamato offer versatile settings and operation modes for a multitude of sterilization processes. Furthermore, Yamato’s large capacity SM steam sterilizers introduce a 7″ interactive touch screen with an immersive display. It delivers extremely clear information about programs, so the sterilizer’s much easier to see & control. Do more with powerful Steam Sterilizers SM520 steam sterilizer, SM530 steam sterilizer, SM820 steam sterilizer, and SM830 steam sterilizer models.
SM Series Comparison
SM Series Large
| SM520 | SM530 | SM820 | SM830 | |
| Heating Drying Pipe | 110V/295W×2 | 110V/295W×2 | 110V/275W ×2 | 110V/275W ×2 |
| 110V/455W×2 | 110V/455W×2 | 110V/625W ×2 | 110V/625W ×2 | |
| Internal Dimensions | ⌀370 x D470 mm | ⌀370 x D470 mm | ⌀370 x D750 mm | ⌀370 x D750 mm |
| External Dimensions WxDxH | 520 x 660 x 881 mm | 520 x 660 x 881 mm | 520 x 660 x 1161 mm | 520 x 660 x 1161 mm |
| Internal Capacity | 50L | 50L | 80L | 80L |
| Power Source (50/60Hz) – Voltage | AC100-120V (no plug, round terminal) | AC200-240V (no plug, round terminal) | AC100-120V (no plug, round terminal) | AC200-240V (no plug, round terminal) |
| Sterilize current | 25-21A | 12.5-10.5A | 25-21A | 12.5-10.5A |
| Dry current | 13.5A | 8.0A | 15.0A | 9.0A |
| Weight | ~113kg | ~113kg | ~137kg | ~137kg |
| Included Accessories | 2 pcs. stainless steel mesh basket (⌀332 x D195.5 mm) | 2 pcs. stainless steel mesh basket (⌀332 x D195.5 mm) | 3 pcs. stainless steel mesh basket (⌀332 x D195.5 mm) | 3 pcs. stainless steel mesh basket (⌀332 x D195.5 mm) |
| OSQ-90 | OSQ-90 | OSQ-90 | OSQ-90 |
Autoclaves and Sterilization template | |
|---|---|
| Voltage (Life Science) | 100-120 VAC Only |
| Max Capacity (Life Sciences) | 50 L (50000 ml) |
| Heating Type (Autoclaves/Sterilization) | Dry Heat, Steam Heat |
| Max Temp (Incubator/Oven/Chamber) | 135 C (275 F) |
Product General Attributes | |
| Warranty | 1 YEARS |
| Product Weight | 249.12 LBS |
| Product Height | 34.6 IN |
| Product Length | 25.9 IN |
| Product Width | 20.4 IN |
| Shipping Weight | 286.4 LBS |
| Power Supply Voltage | 110V |
| Shipping Height | 40 IN |
| Shipping Length | 30 IN |
| Shipping Width | 23.46 IN |
