Amprobe AC50A – AC Leakage Clamp Meter
18 people are viewing this product right now
Original price was: $719.38.$555.22Current price is: $555.22.
Shipping calculated at checkout.
Estimated delivery:4 days
Compact Clamp Meter For Leakage Current
- AC current measurement to 60 A
- Leakage current measurement with resolution of 0.01 mA
- AC voltage to 400 V
- Resistance measurement and continuity beeper
- Min/max control to see largest or smallest values in a series of measurements
- Relative value measurement to determine differentials
- Data hold to freeze measurement value on the display
- Digital display with analog bargraph
- Jaw opening 1.2″
- Auto-power off to save battery life
Guarantee Safe and Secure Payment Checkout
Description
Amprobe AC50A
- AC current measurement to 60 A
- Leakage current measurement with a resolution of 0.01 mA
- AC voltage to 400 V
- Resistance measurement and continuity beeper
- Min/max control to see largest or smallest values in a series of measurements
AC Leakage Clamp Meter
The Amprobe AC50A Clamp Multimeter with leakage current capability measures low AC current in the microamps. Great for applications requiring measurement of leakage and fault currents.
Clamp Meters/Clamp Meters Template | |
|---|---|
| True RMS | No |
| Maximum Current AC | 60 A |
| Maximum Voltage AC | 400 V |
| Maximum Conductor Size | 1.2 IN |
| Resistance | Yes |
| Capacitance | No |
| Auto Ranging/Manual | Manual |
| In-Rush Current | No |
Product General Attributes | |
| Unique Features | Relative Value Measurement to Determine Differentials, Data Hold to Freeze Measurement Value on the Display, Digital Display |
| Additional Info/Comments | Heavy Duty Test Leads with Threaded Alligator Clips |
| Product Weight | 7 OUNCES (0.438 LBS) |
| Product Height | 1.4 IN |
| Product Length | 7.2 IN |
| Product Width | 2.5 IN |
| Data Logging | No |
| HTS/Schedule B Number | 9030.32.0000 HTS/Schedule B Number Value not available |
| ECCN Number | 3A992 ECCN Number Value not available |
| Battery Type | Other |
| Power Supply Voltage | Battery Powered Power Supply Voltage Battery Operated Device |
| Country of Origin | Taiwan Country of Origin Value not available |
| Other Information | Display: 3-3/4, LCD incl. functions and symbols Bargraph: 40 segments Range Selection: manual Auto-Power-Off: approx. 30 min. Overload display: the left digit is blinking Measuring rate: 20 measurements/sec. (Bargraph), 2 measurements/sec. (LCD) Clamp opening: ca. 30 mm (1.2?) Overvoltage Categorie: CAT II, 600 V, CAT III, 300 V Pollution degree: 2 Height above MSL.: up to 2000 m, indoor operation Battery display: at low battery Power supply: Battery 2 x 1,5 V IEC LR6 (alkaline) Current Consumtion: approx. 10 mA Operation temperature: -10? C ? 50? C (14? F… 122? F) Storage temperature: -20? C ? 60? C (-4? F… 140? F) Humidity: 75 % relative humidity |
You must be logged in to post a review.
Manuals/Guides
ManualsSpec Sheets
| Dimensions | 7.2 × 2.5 × 1.4 in |
|---|
