BK 9115B-AT – Multi-Range Programmable DC Power Supply with Automotive Test Function, No GPIB
15 people are viewing this product right now
Shipping calculated at checkout.
Estimated delivery:3 days
1200W Multi-Range 80V/60A DC Power Supply with Automotive Test – NO GPIB
- Includes Automotive Test Function
- Voltage: 0 – 80V
- Current: 0 – 60A
- Compact, high density, 1U rackmount form factor
- High programming and readback resolution
- Adjustable voltage rise and fall times
- Sequence programming
- Store and recall up to 100 instrument settings
- Standard USB (USBTMC-compliant), RS-232, and RS-485 interfaces supporting SCPI commands for remote control
Guarantee Safe and Secure Payment Checkout
Description
BK 9115B-AT
- Includes Automotive Test Function
- Voltage: 0 – 80V
- Current: 0 – 60A
- Compact, high density, 1U rackmount form factor
- High programming and readback resolution
Multi-Range Programmable DC Power Supply with Automotive Test Function, No GPIB
The BK Precision 9115-AT can replace several supplies on your bench or in your rack. Unlike conventional supplies with fixed output ratings, this multi-range power supply automatically recalculates voltage and current limits for each setting, providing full output power in any Volt/Amp combination within the rated voltage and current limits.
For benchtop applications, this model provides a numerical keypad for direct data entry along with convenient cursors and analog-style knobs to quickly make incremental voltage or current changes. Systems integrators benefit from the standard USB (USBTMC-compliant), RS-232, and RS-485 interfaces supporting SCPI commands.
The 9115-AT provides automotive power test waveforms compliant to DIN 40839 and ISO 16750-2:2012(E) standards that can simulate common test conditions for electrical and electronic devices installed in automobiles.
Power Supplies/DC Power Supplies Template | |
|---|---|
| Outputs | Single |
| Voltage Output 1 | Variable |
| Max Voltage Output 1 | 80 V |
| Programmable | Yes |
| Current Output 1 | Variable |
| Max Current Output 1 | 60 A |
| Meter Type | Digital |
| Switching | Yes |
| Linear/Switching | Switching |
| Max Display Resolution Current | 1 mA |
| Max Display Resolution Voltage | 1 mV |
| Constant current/voltage | Yes |
| Remote Sensing | Yes |
Product General Attributes | |
| Safety Approval | CE |
| Interfaces I/O | Other, RS-232, RS-485, USB |
| Product Weight | 18.74 LBS |
| Product Height | 1.75 IN |
| Product Length | 19.02 IN |
| Product Width | 16.32 IN |
| Shipping Weight | 30.00 LBS |
| Data Logging | Yes |
| HTS/Schedule B Number | 8504.40.9580 |
| ECCN Number | 3A992 |
| Calibration Included | Factory Calibration |
| Power Supply Voltage | 120V/220V Universal |
| Country of Origin | China |
| Shipping Height | 9 IN |
| Shipping Length | 25 IN |
| Shipping Width | 24 IN |
You must be logged in to post a review.
Manuals/Guides
Brochures
| Weight | 18.74 lbs |
|---|---|
| Dimensions | 19.02 × 16.32 × 1.75 in |
