BK 9201B – Multi-Range Programmable DC Power Supply, 200W, 60V, 10A, No GPIB

Name: BK 9201B - Multi-Range Programmable DC Power Supply, 200W, 60V, 10A, No GPIB - NESTES Instruments
SKU: B&K Precision 9201B
Price: 898.77 USD
Availability: InStock

Brand:

B&K-Precision

Please, activate Wishlist option to use this widget.

Please, activate Compare option to use this widget.

18 people are viewing this product right now

Original price was: $1,023.00.Current price is: $898.77.

Shipping calculated at checkout.

Add to quote

Estimated delivery:3 days

Multi-Range 60V/10A/200W DC Power Supply – NO GPIB

Voltage: 0-60 V
Current: 0-10 A
Max Power: 200 W
Multi-ranging operation
High programming and readback resolution of 1 mV/0.1 mA
Output timer function
List mode programming
Store and recall up to 72 instrument settings
Standard USB (USBTMC-compliant), RS-232, and interfaces supporting SCPI commands for remote control
Remote sense

SKU: B&K Precision 9201B EAN: 094308434544 Tags: DC Power Supplies / Lab Power Supplies, Power Supplies Categories: DC Power Supplies / Lab Power Supplies

Have any Questions?

Feel free to Get in touch

Guarantee Safe and Secure Payment Checkout

Description

Reviews (0)

Manuals/Guides

Description

BK 9201B

Voltage: 0-60 V
Current: 0-10 A
Max Power: 200 W
Multi-ranging operation
High programming and readback resolution of 1 mV/0.1 mA

Multi-Range Programmable DC Power Supply, 200W, 60V, 10A, No GPIB

The BK Precision 9201 can replace several supplies on your bench or in your rack. Unlike conventional supplies with fixed output ratings, this multi-range power supply automatically recalculates voltage and current limits for each setting, providing full output power in any Volt/Amp combination within the rated voltage and current limits.

For benchtop applications, this power supply provides a numerical keypad for direct data entry along with convenient cursors and analog-style knobs to quickly make incremental voltage or current changes. System integrators benefit from the standard USB (USBTMC-compliant), RS-232, and GPIB interfaces supporting SCPI commands.
