Comet T7613D – Web Sensor with PoE, Duct Mount Remote Thermometer Hygrometer Barometer with Ethernet Interface

• Measured values: temperature, humidity, pressure
• Atmospheric pressure measurement range: 600 to 1,100 hPa
• Temperature measurement range: -30 to +105 °C
• Humidity measurement range: 0 to 100 % RH
• Output: Ethernet

Premium Web Sensors with Ethernet connection are designed for the accurate measurement of temperature, relative humidity, CO2, and barometric pressure of air in non-aggressive environments.

The T7613D is a t-line Web sensor for measuring temperature, humidity, and atmospheric pressure with a remote alarm. The T7613D uses built-in temperature, humidity, and atmospheric pressure sensors. The Web Sensor is equipped with an LCD display for showing current measured values. The Web Sensor can be integrated into the control systems of different manufacturers by connecting directly to a computer network using SNMP, MODBUS TCP, SOAP, syslog. The device setup can be made by the TSensor software which can be downloaded for free from the manufacturer’s website. One advantage of Web Sensors is the configuration of settings via web interface.

Upper and lower limits can be set for the alarm, which can be indicated via email or by color LED.

The visual indication of CO2 concentration is provided by three-color LED:

• ​LED shines green – CO2 concentration 0 to 1,000 ppm
• LED shines yellow – CO2 concentration 1,001 to 1,200 ppm
• LED shines red – CO2 concentration 1,201 ppm and more

The high-precision capacitive polymer sensor ensures excellent long-term calibration stability and ultimate accuracy. Power over the Ethernet feature is in accordance with IEEE 802.3af. Measured values are also converted to other humidity interpretation: dew point temperature, absolute humidity, specific humidity, mixing ratio, and specific enthalpy.
