Electrothermal PS80010 – RS1000 Reaction Station 230V, 50-60Hz, 300W

• Sample sizes from 1ml to 25ml
• Controlled temperature range from ambient +5°C to 150°C
• Powerful stir speed from 400 to 2000rpm
• Manual and external control via the RS232/RS485 interface ports

The STEM RS1000 Reaction Station has 10 positions that can be programmed to run at the same temperature and stirring rate simultaneously. It can be used for a wide range of applications from simple synthesis in the laboratory to process optimisation in industry.

This product is designed to meet the demands of today’s modern laboratory and has been meticulously designed to provide years of service when used as described in the following pages. This product is a 10-positioned heat and stir reaction station designed for use with 24 or 25 mm diameter glass vessels. (Variant dependant).

At the heart of this product is an innovative, firmware package designed to provide enhanced, accurate temperature control of the block or vessel. Temperature is sensed by a high precision platinum sensor embedded within the vessel block. A microprocessor constantly monitors temperature change many times per second. The products temperature range is from ambient to 150°C.

Linked DC motors provide optimum speed control and sensitivity to drive the stir facility. High performance magnetic sensors carefully measure speed control via a feedback loop controlled by quartz oscillator and a microprocessor. The stir speed range is 400 – 2000rpm.

The vessel block is aluminium with a Teflon coating. The raised case walling reduces heat loss, which improves energy efficiency and adds to the protection of the user.
