HIKMICRO Pocket 2 – Pocket Thermal Imaging Camera with WiFi, 256×192 Thermal Resolution

• Thermal Resolution: 256×192; NETD: < 40 mK (at 25°C), F# 1.0
• Digital Resolution: Configurable 2MP, 5MP, 8MP
• WiFi: 802.11 b/g/n (2.4GHz + 5GHz); Bluetooth 4.2
• Accuracy: Max. (+/- 2°C/3.6°F, +/- 2%)

• Object Temperature Range: -20°C to 400°C (-4°F to 752°F)

The HIKMICRO Pocket Series is equipped with a high-resolution HIKMICRO VOx 256 x 192 (49,152 pixels) detector, a high-resolution configurable 2MP, 5MP, 8 MP optical lens, and a 3.5in LCD touch screen. The 3 level/span modes (manual, auto, 1-tap) improve the image contrast and help the user locate faults faster and more efficiently, and to measure temperatures more accurately. The wide temperature range of -20 °C to 400 °C is ideal for building inspections, HVAC, electrical, and mechanical equipment maintenance. The 25 Hz frame rate allows for smooth operation and the Wi-Fi function allows the Pocket to share images in real-time and connect to the HikMicro Viewer App.

Use the HIKMICRO Viewer App for transmitting pictures from the camera to a mobile phone. Analyze, share images and generate simple reports in real-time on-site. Use HIKMICRO Analyzer PC software to provide customers with professional reports with images documenting problems and repairs.

HikMicro Pocket 2 Features and Functions

• HikMicro VOx detector 256×192 thermal resolution (NETD < 40 mK) – ultra high resolution
• Multiple image modes – Thermal, Fusion, PIP, Optical
• Measurement presets – center spot, hot spot, cold spot, off
• Portable design fits easily into pocket and tool bag
• IP54 rating and 2-meter drop test protection suitable for industrial use
• 3.5in color LCD Touch Screen display; 640×480 resolution; 1x to 4x digital zoom
• Level and span modes (Auto, Manual, 1-tap touchscreen)
• WiFi Connectivity; Bluetooth – connect to a mobile device, HikMicro Viewer App
• High-temperature alarm – audio/visual alerts to high temperatures
• LED work light – work safely in dark environments
• 7 Color palettes – white hot, black hot, rainbow, iron bow, red hot, fusion, rain
• HikMicro Analyzer Software – offers flexible ways to analyze info (points, rectangles and more)
• 25 Hz fast image frequency – smooth video, measurements if panning scenes, moving targets
• 4hrs continuous running battery life
• Field of View – 50° x 37.2°
• Storage 16GB internal; 60K images, 10hrs video, radiometric JPEG with measurement data
