JBC TESE-1QB – Precision Hot Air Station without Extractor Desk

• Precision hot air station
• This model does not include the extractor desk
• Designed for repairing small and medium size surface mount components
• Memory for up to 25 temperature profiles
• Automatically turns off when tool is placed in stand

The JBC TESE-1QB is a precision hot air station for repairing small and medium size surface mount components. This model does not include the extractor desk.

For compatible nozzles, click here.

For protectors, click here.

For protectors, click here.

There are two work modes to choose from – manual and profile. In manual mode, the operator can set temperature values and air flow rate depending on the task. In profile model, the operator can set up and edit as many as 25 profiles for temperature and airflow.

Users can read the temperature at a specific point on the PCB with the control thermocouple. This helps protect components or a specific area on the PCB, and provides greater precision when regulating the temperature.

There are two work modes available for use with the control thermocouple:

• Regulation: the station regulates the air temperature automatically to maintain the External Thermocouple (TC) temperature.
• Protection: the station cuts the air supply off when the External Thermocouple (TC) temperature is reached.

The auto-stop function is a safety measure which guarantees the heat is automatically cut off when the tool is in the stand. This also means you save power and extend the life of the tip. There is also an auto start feature. When selected, the tool automatically heats up when lifted from the stand.
