PCE PCE-228-R – Redox Meter

• Includes ORP-14 sensor (redox) and stainless-steel temperature sensor
• Measures redox and temperature (pH measurements with optional sensor not included)
• Redox measuring range: 1999 – 0 – 1999 mV
• Temperature measuring range (sensor): 0 – 65 C
• Automatic three-point calibration

PCE-228-R Redox meter / Portable Redox Meter, for both pH and temperature values / RS-232 interface and optional software

PCE-288-R Redox Meter is a very easy-to-use meter to measure mV / pH / ºC. In the PC-228-R Redox Meter values can be directly stored in the SD memory card (Excel format) or can be directly transferred in real-time to a PC or laptop by means of the RS-232 interface. Both Redox value and temperature can be directly transferred to a PC by means of the RS-232 interface, so we offer you software and an RS-232 data cable as additional components.

Temperature compensation (function available only for measurements of pH) can be made by hand or automatically by means of a temperature sensor included in the delivery of the Redox Meter. So, all the previously mentioned characteristics provide this Redox Meter with high reliability. The PCE-228-R Redox Meter has a three-point calibration. Redox, temperature, and pH values can be determined by means of the combined meter. To determine the pH value an additional pH electrode must be purchased. You can find the pH electrode in the accessories tab. We recommend you use the PW 03 electrode. PCE-228-R Redox Meter is powered by batteries (one 9V battery is included in the delivery).
